Yokogawa ANR10D-420/ATDOC/NDEL Node Unit for Dual-Redundant ER Bus

Yokogawa ANR10D-420/ATDOC/NDEL Node Unit for Dual-Redundant ER Bus

  • Manufacturer: Yokogawa

  • Product No.: ANR10D-420/ATDOC/NDEL

  • Condition:1000 in stock

  • Product Type: Node Unit for Dual-Redundant ER Bus

  • Product Origin: Japan

  • Payment: T/T, Western Union

  • Weight: 10000g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • 24/7 Support
  • 30-Day Returns
  • Fast Shipping

Product Overview

The Yokogawa ANR10D-420/ATDOC/NDEL is a Node Unit for Dual-Redundant ER Bus, categorized as a "Remote Node" in Yokogawa’s system architecture. Unlike the ANB10S and ANB10D (ESB Bus Node Units or Local Nodes), which connect directly to a Field Control Unit (FCU) via an ESB bus, the ANR10S and ANR10D connect to an EB401 ER Bus Interface Master Module within an ESB Bus Node Unit via an ER bus. This 19” rack-mountable unit is designed for reliable, redundant operation in industrial control environments.

Technical Information

Item Specifications
Power Supply Voltage: 100-120 V AC, Frequency: 50/60 Hz
Voltage: 220-240 V AC, Frequency: 50/60 Hz
Voltage: 24 V DC
(Specify with Suffix Codes)
Electric Power Consumption 100-120 V AC: 200 VA, 120 W
220-240 V AC: 230 VA, 120 W
24 V DC: 5.5 A
Weight 10 kg (including 8 IOMs)

Model and Suffix Codes

  • Model: ANR10D Node Unit for Dual-Redundant ER Bus (19” Rack Mountable)
  • Suffix Codes:
    • -4: Dual-redundant power supply
    • 1: 100-120 V AC power supply
    • 2: 220-240 V AC power supply
    • 4: 24 V DC power supply
    • 5: Basic type with no explosion protection
    • 6: With ISA G3 option, temperature (-20 ˚C to 70 ˚C) option, and no explosion protection
    • E: Basic type with explosion protection
    • F: With ISA G3 option, temperature (-20 ˚C to 70 ˚C) option, and explosion protection
  • Option Codes:
    • /ATDOC: Explosion Protection Manual
    • /NDEL: Software License for Node Expansion (Mandatory for connection with AFF50 or AFV10)

Specific Configuration

  • Model/Part Number: ANR10D-420/ATDOC/NDEL
  • Configuration Details:
    • -4: Dual-redundant power supply
    • 2: 220-240 V AC power supply
    • 0: Not explicitly listed in suffix codes but implied as a placeholder (possibly a typo or standard convention)
    • /ATDOC: Includes Explosion Protection Manual
    • /NDEL: Includes Software License for Node Expansion
