Product Description
🔹 General Information
|
Manufacturer |
Yokogawa |
|---|---|
|
Model/Part Number |
ANT401-50 |
|
Model Type |
Optical ESB Bus Repeater Module |
|
Description |
Master module for ESB bus optical transport (up to 5 km) |
🔹 Standard Specifications
|
Function |
ESB bus optical transport |
|---|---|
|
Connection Types |
Chain type and star type |
|
Max. Connectable Stages |
2 (chain type connection) |
|
Max. Number of Connections |
8 (chain and star type, paired ANT401–ANT502 connections) |
|
Transmission Distance |
Up to 5 km (with ANT401, ANT502, and ANB11) |
|
Current Consumption |
0.5 A (for ANT401/ANT502) |
|
Weight |
Approx. 0.25 kg (main body only) |
🔹 Optical Fiber Cable Specifications
|
Connector Type |
LC (IEC61754-20 compliant) |
|---|---|
|
Optical Fiber Type |
Quartz single-mode optical fiber |
|
Required Number of Cores |
2 |
|
Max. Permissible Optical Loss |
0 to 10 dB @ 1.3 μm |
|
Max. Cable Length |
5 km |
🔹 Model and Suffix Codes
|
Model |
Description |
|---|---|
|
ANT401 |
Optical ESB Bus Repeater Master Module (5 km range) |
Suffix Codes:
|
Code |
Description |
|---|---|
|
-5 |
Standard type (no explosion protection) |
|
-E |
Explosion protection type |
|
0 |
Basic type |
|
3 |
With ISA Standard G3 & extended temperature (-20°C to 70°C) |
Option Codes:
|
Code |
Description |
|---|---|
|
/CU1N |
Connector unit for ESB Bus |
|
/CU1T |
Connector unit with terminator for ESB Bus |
