Triconex 9771-210F Analog Input Termination Panel
Triconex 9771-210F Analog Input Termination Panel
Manufacturer: Triconex
Product No.: 9771-210F
Condition:1000 in stock
Product Type: Analog Input Termination Panel
Product Origin: USA
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
___
Product Overview
|
Field |
Details |
|---|---|
|
Manufacturer |
Triconex |
|
Model/Part Number |
9771-210F |
|
Model Type |
Analog Input Termination Panel (Current Input, User-Configurable, 0_5 VDC) |
|
Description |
Termination panel for analog input modules. Supports 0_5 VDC, 0_10 VDC, and ±5 VDC inputs. User-configurable. Provides 16 current input points with current-limited and isolated connections. |
_
_
___
Technical Specifications _ 9771-210F
|
Feature |
Specification |
|---|---|
|
Panel Type |
Current input, user-configurable |
|
Number of Points |
16 |
|
Power Terminals |
16 (+), each current-limited with 180 _ resistor |
|
Current Input Terminals |
16 (_), each with precision 250 _ resistor (for 0_5 VDC conversion) |
|
Input Configuration |
Supports 0_5 VDC, 0_10 VDC, and _5 to +5 VDC ranges |
|
Power Supply Redundancy |
Yes _ redundant 24 VDC inputs supported via diode ORing |
|
Labeling |
Two sets: 1_16 and 17_32 (for 32-pt module compatibility) |
_
_
__
Compatible Modules
|
Module Part Number |
Points per Module |
Module Description |
|---|---|---|
|
3700 |
32 |
0_5 VDC, non-commoned, differential, DC-coupled, TMR |
|
3700A |
32 |
0_5 VDC, non-commoned, differential, DC-coupled, TMR with +6% over-range |
|
3703E |
16 |
0_5 VDC or 0_10 VDC, non-commoned, differential, isolated, TMR (TriStation configurable) |
|
3721 |
32 |
0 to 5 VDC or _5 to +5 VDC, differential, DC-coupled, TMR (TriStation configurable) |
_
_
| _Check below popular items for more information in_ | Industrial Control Hub | |||
| Brand | Description | Price(USD) | Stock | Link |
| Triconex | 3301 32-Point Digital Input Module 24 VDC | 100-957 | 524 | 3301 Digital Input Controller |
| Triconex | 7400213-100 Digital Input Module | 350-1350 | 913 | 7400213-100 Digital Input Controller |
| Triconex | 9674-810 Digital Output Termination Panel | 156-1156 | 559 | 9674-810 Termination Panel Controller |
| Triconex | 9761-210F Analog Input Termination Panel | 100-786 | 306 | 9761-210F Termination Panel Controller |
| Triconex | 3625C1-J Digital Output Module | 4500-5500 | 148 | 3625C1-J Digital Output Controller |
| Triconex | AP3101 Communication Module | 4925-5925 | 122 | AP3101 Communication Controller |
| Triconex | T8461C Digital Output Module | 10000-11000 | 407 | T8461C Digital Output Controller |
