Triconex 3301 32-Point Digital Input Module (24 VDC)
Triconex 3301 32-Point Digital Input Module (24 VDC)
Manufacturer: Triconex
Product No.: 3301
Condition:1000 in stock
Product Type: 32-Point Digital Input Module (24 VDC)
Product Origin: USA
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
___
Product Overview
|
Field |
Details |
|---|---|
|
Manufacturer |
Triconex |
|
Model/Part Number |
3301 |
|
Description |
32-Point Digital Input Module (24 VDC) |
_
_
___
Technical Specifications
|
Attribute |
Specification |
|---|---|
|
Number of Input Points |
32 (commoned) |
|
Nominal Input Voltage |
24 V DC |
|
Operational Voltage Range |
15_30 V DC |
|
Absolute Max Input Voltage |
33 V DC |
|
Max Reverse Input Voltage |
_0.6 V DC |
|
Input Delay |
< 10 ms (On to Off or Off to On) |
|
Time Constant (TC) |
6.4 ms, _3 dB @ 25 Hz |
|
Input Impedance |
> 30 k_ (without baseplate); _ 3 k_ (with baseplate) |
|
Input Power Consumption |
0.2 W/pt @ 24 V DC; 0.5 W/pt @ 33 V DC |
|
Input Thresholds |
0_5 V DC = Off; 6_14 V DC = Transition; 15_30 V DC = On |
|
Diagnostics |
Force-to-Value Diagnostic (FVD), < 2 ms/test |
|
Max Toggle Rate (for diagnostic integrity) |
< 20 toggles/sec |
|
FVD Off-State Glitch Duration |
< 2 ms |
|
FVD Off-State Glitch Magnitude |
_ 36% of test voltage |
|
Output Impedance (0_5 V DC) |
_ 100 k_ |
|
ADC Scan Time |
< 1 ms (for all 32 points) |
|
Functional-to-Protective Earth Isolation |
_ 500 V DC |
|
Functional-to-Logic Earth Isolation |
_ 800 V DC |
_
| _Check below popular items for more information in_ | Industrial Control Hub | |||
| Brand | Description | Price(USD) | Stock | Link |
| Triconex | 4000212-020 Trident Extender Bus Assembly Kit | 100-544 | 961 | 4000212-020 Extender Bus Kit Controller |
| Triconex | 9563-810F Termination Panel Digital Input | 100-786 | 245 | 9563-810F Termination Panel Controller |
| Triconex | 3000400-530 Terminal Block | 100-566 | 903 | 3000400-530 Terminal Block Controller |
| Triconex | 8112 Remote Expansion Chassis | 5829-6829 | 439 | 8112 Remote Expansion Chassis Controller |
| Triconex | 4117 Enhanced Intelligent Communication Module | 214-1214 | 553 | 4117 Communication Controller |
| Triconex | 7400061-210-A3 AI/TC Termination Panel | 571-1571 | 576 | 7400061-210-A3 Termination Panel Controller |
| Triconex | 3481 S2 Analog Output Module | 3071-4071 | 900 | 3481 S2 Analog Output Controller |
