Product Description
🔍
Product Overview
|
Field |
Details |
|---|---|
|
Manufacturer |
Triconex |
|
Model/Part Number |
9762-210 |
|
Model Type |
Analog Input Termination Panel (Current Input, 0–5 VDC) |
|
Description |
Termination panel designed for analog input modules, supporting 16 current inputs and redundant power supplies. |
⚙️
Technical Specifications – 9762-210
|
Feature |
Specification |
|---|---|
|
Panel Type |
Current input |
|
Number of Points |
16 |
|
Power Terminals |
16 positive terminals (+), current-limited via 180 ohm series resistors |
|
Current Input Terminals |
16 negative terminals (–), each with precision 250 ohm current-to-voltage conversion resistors |
|
Power Redundancy Support |
Yes – supports redundant 24 VDC sources via diode ORing |
|
Application Note |
Designed to work with differential and isolated analog inputs |
🔌
Compatible Modules
|
Module Part Number |
Points per Module |
Description |
|---|---|---|
|
3703E |
16 |
0–5 VDC or 0–10 VDC analog input, non-commoned, differential, isolated, TMR |
