Product Description
Product Overview
The Triconex 4000093-310 is an External Termination Panel designed for use within the Tricon safety instrumented system (SIS) by Triconex, a brand under Schneider Electric (formerly Invensys). This module serves as an external termination assembly (ETA), providing a secure and organized interface for connecting field wiring to Tricon I/O modules, specifically for digital output applications. It supports the Triple Modular Redundant (TMR) architecture, ensuring fault-tolerant connectivity for safety-critical applications in industries such as oil & gas, petrochemical, and power generation.
Technical Specifications
The 4000093-310 has the following specifications based on standard characteristics for this model:
| Item | Specification |
|---|---|
| Model/Part Number | 4000093-310 |
| Manufacturer | Triconex (Schneider Electric) |
| Description | External Termination Panel (Digital Output) |
| Series | Tricon SIS |
| Channels | 16 digital output channels |
| Voltage Rating | 24 VDC (field side) |
| Connection Type | Screw terminals for field wiring |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Weight | 0.5 kg |
Additional Details
The 4000093-310 includes the following additional information based on its standard use and documentation:
| Category | Details |
|---|---|
| Function | Terminates field wiring for digital output modules |
| Mounting | DIN rail or panel mounting, external to Tricon chassis |
| Compatibility | Tricon Digital Output Modules (e.g., 3601E, 3625) |
| Features | Supports TMR architecture, fused connections, easy wiring access |
| Certifications | Meets IEC 61508 SIL 3, UL, and CE standards |
| Part Type | New, surplus, or refurbished |
