Product Description
Triconex 3000656-210C1R (3000656-210) External Termination Assembly
Product Overview
- The Triconex 3000656-210C1R, also referred to as 3000656-210, is an External Termination Assembly designed for the Triconex Safety Instrumented System (SIS), part of Schneider Electric’s EcoStruxure Tricon platform. It serves as a termination panel for connecting field wiring to Triconex I/O modules, ensuring secure and reliable signal transmission in safety-critical applications. Used in industries such as oil and gas, chemical, and power generation, it supports the Triple Modular Redundant (TMR) architecture, maintaining Safety Integrity Level 3 (SIL3) compliance.
Technical Specifications
- The 3000656-210C1R has the following specifications based on standard characteristics for this model:
| Specification | Details |
|---|---|
| Model/Part Number | 3000656-210C1R (3000656-210) |
| Manufacturer | Triconex (Schneider Electric) |
| Description | External Termination Assembly for Termination Panel |
| Series | Tricon Safety System |
| Connection Type | Screw or compression terminals |
| Signal Compatibility | Analog and digital signals (e.g., 4-20 mA, 24V DC) |
| Voltage Rating | Up to 250 V AC/DC |
| Current Rating | Up to 8 A |
| Mounting | DIN rail or panel mount |
| Operating Temperature | -20°C to 60°C (-4°F to 140°F) |
| Humidity | 5% to 95% non-condensing |
| Weight | Approx. 0.5 kg |
Additional Details
- The 3000656-210C1R includes the following additional information based on its standard use and documentation:
- Function: Provides a reliable interface for field wiring to Triconex I/O modules, supporting analog and digital signals for applications like emergency shutdown (ESD), fire and gas detection, and process control. Ensures signal integrity within the TMR framework for safety-critical operations.
- Mounting: Designed for DIN rail or panel mounting; connects to Triconex I/O modules in chassis like 8110 or 8400 via standard cabling, facilitating easy installation and maintenance.
- Compatibility: Compatible with Tricon v9.6 and later systems; supports I/O modules such as 3503E (digital input), 3700A (analog input), and others requiring external termination. Integrates with TriStation 1131 software for system configuration.
