Triconex 9563-810F Termination Panel (Digital Input)
Triconex 9563-810F Termination Panel (Digital Input)
Manufacturer: Triconex
Product No.: 9563-810F
Condition:1000 in stock
Product Type: Termination Panel (Digital Input)
Product Origin: USA
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
___
Product Overview
|
Field |
Details |
|---|---|
|
Manufacturer |
Triconex |
|
Model/Part Number |
9563-810F |
|
Model Type |
Termination Panel (Digital Input) |
|
Application |
Used with Triconex 24 V digital input modules |
_
_
___
Technical Specifications _ 9563-810F
|
Feature |
Description |
|---|---|
|
Panel Type |
Commoned |
|
Input Points |
16 |
|
Leakage Current |
Max: 3.3 mATypical: 2.5 mA |
|
Fuse Type |
1A, slow-blow (one per point) |
|
Fuse Indicator |
Yes (blown-fuse LED indicator) |
|
Power Terminals |
Commoned PWR+ and PWR_ |
|
Labeling Options |
Two sets: 1_16 and 17_32 |
_
_
__
Usage Notes
_
-
Since Triconex digital input modules have_32 points, you must use_two 9563-810F panels_per module.
-
Ideal for installations where fuse protection and individual fuse status monitoring are needed.
_
_
_
Compatible Digital Input Modules
|
Module Part Number |
Points |
Description |
|---|---|---|
|
3503E |
32 |
24 VAC/VDC, commoned in groups of 8, TMR with self-test |
|
3505E |
32 |
24 VDC, low-threshold, commoned in groups of 8 with self-test, TMR |
_
_
| _Check below popular items for more information in_ | Industrial Control Hub | |||
| Brand | Description | Price(USD) | Stock | Link |
| Triconex | 7400207-001 Main Processor Baseplate | 231-1231 | 288 | 7400207-001 Processor Baseplate Controller |
| Triconex | 3008 V10.4 Main Processor Module | 1357-2357 | 868 | 3008 V10.4 Processor Controller |
| Triconex | 4211 Remote Extender Module | 18487-19487 | 627 | 4211 Remote Extender Controller |
| Triconex | 2000361-001 Cable Assembly | 400-1400 | 544 | 2000361-001 Cable Assembly Controller |
| Triconex | 3603T Digital Output Module | 6733-7733 | 525 | 3603T Digital Output Controller |
| Triconex | AI3351 S2 Analog Input Module | 1643-2643 | 676 | AI3351 S2 Analog Input Controller |
| Triconex | CIM3211 Communication Module | 786-1786 | 671 | CIM3211 Communication Controller |
