Product Description
Triconex 4117 Enhanced Intelligent Communication Module
Product Overview
- The Triconex 4117 is an Enhanced Intelligent Communication Module (EICM) designed for use in Triconex safety systems, part of Schneider Electric’s Tricon platform. It facilitates communication between the Tricon system and external devices, supporting protocols like Modbus and interfaces for printers and TriStation 1131. The module is ideal for safety-critical applications in industries such as oil and gas, chemical, and power generation, ensuring reliable data exchange for process control and monitoring.
Technical Specifications
- The 4117 has the following specifications based on standard characteristics for this model:
| Specification | Details |
|---|---|
| Model/Part Number | 4117 |
| Manufacturer | Triconex (Schneider Electric) |
| Description | Enhanced Intelligent Communication Module (EICM) |
| Series | Tricon Safety System |
| Serial Ports | 4 (configurable as RS-232, RS-422, or RS-485) |
| Parallel Port | 1 (Centronics interface for printer) |
| Communication Protocols | Modbus (RTU or ASCII), TriStation 1131 |
| Data Rate | Up to 57.6 kbps aggregate for all serial ports |
| Modbus Support | Master or slave, up to 7 Modbus masters per chassis |
| Power Consumption | Approx. 10 W |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Weight | Approx. 1 kg |
Additional Details
- The 4117 includes the following additional information based on its standard use and documentation:
- Function: Enables communication with Modbus masters/slaves, TriStation 1131 for configuration, and printers for logging; supports concurrent operation of all ports for efficient data exchange.
- Mounting: Installs in a Tricon chassis slot, interfacing with the system via the backplane; mechanically keyed for correct slot placement.
- Compatibility: Compatible with Tricon v9 and v10 systems; supports integration with external devices like PLCs, DCS, and HMI systems via Modbus.
- Configuration: Configurable via TriStation 1131 software; each serial port can be independently set as Modbus master or slave with RTU or ASCII mode.
- Certifications: Meets UL, CE, and Factory Mutual (FM) standards for Class I, Division 2 hazardous locations; complies with IEC 61131 for environmental and EMC requirements.
