Product Description
Product Overview
| Category | Details |
|---|---|
| Manufacturer | Triconex (Schneider Electric) |
| Model/Part Number | 2301 |
| Description | Digital Input Baseplate Kit for Triconex Trident safety systems, designed to interface with digital input modules for low-voltage applications |
| Key Features | Supports 24 VAC/VDC digital inputs, triple modular redundancy (TMR), includes I/O baseplate and interconnect assembly, hot-swappable, SIL 3 certified |
Technical Specifications
| Specification | Details |
|---|---|
| Model | 2301 |
| Product Type | Digital Input Baseplate Kit |
| Series | Trident Safety System |
| Input Voltage | 24 VAC/VDC |
| Components | I/O Baseplate, I/O Interconnect Assembly, Slot Cover, Terminal Cover |
| Power Supply | 24 VDC (via chassis backplane) |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Dimensions | Approx. 300 x 100 x 200 mm (11.8 x 3.9 x 7.9 in) |
| Weight | Approx. 1.5 kg (3.3 lbs) |
| Certifications | SIL 3 (IEC 61508), CE |
External Connection Options
| Connection Type | Details |
|---|---|
| Supported Connections | Terminal cover for field wiring, integrates with Trident chassis backplane |
Functional Features
| Feature | Details |
|---|---|
| Digital Input Interface | Connects digital input modules to field devices for monitoring |
| Redundancy | Supports TMR architecture for fault-tolerant operation |
| Hot-Swappable | Allows module replacement without system shutdown |
| Diagnostics | Built-in diagnostics for input status and baseplate health |
Model and Configuration
| Category | Details |
|---|---|
| Base Model | 2301 |
| Configuration | Standard, non-redundant baseplate, compatible with 3301 digital input module |
