Product Description
Product Overview
The Allen-Bradley 1771-WN is a Field Wiring Arm with 32 terminals, designed for use with PLC-5 1771 I/O modules in industrial automation systems. Manufactured by Allen-Bradley, a brand under Rockwell Automation known for its dependable control solutions, this wiring arm provides a robust connection point for field wiring, such as sensors and actuators, to high-density digital I/O modules like the 1771-IBN (32-point input) and 1771-OBN (32-point output). It features 40 pins with 32 active screw-clamp terminals, supporting wire sizes up to 14 AWG, and includes a hinged, swing-away design for easy installation and removal without disturbing connected wires. The 1771-WN is optimized for modules requiring extensive I/O points, making it suitable for legacy PLC-5 systems in industries such as manufacturing and process control. As part of the discontinued 1771 series, it remains critical for maintaining existing installations.
Technical Information
| Item | Specifications |
|---|---|
| Manufacturer | Allen-Bradley (Rockwell Automation) |
| Series | PLC-5 (1771) |
| Model/Part Number | 1771-WN |
| Description | Field Wiring Arm, 32 Terminals |
| Terminal Count | 32 screw-clamp terminals (40-pin connector) |
| Wire Size | 22-14 AWG (0.324-2.08 mm²) |
| Terminal Torque | 7-9 lb-in (0.8-1 Nm) |
| Compatibility | 1771 I/O modules (e.g., 1771-IBN, 1771-OBN) |
| Operating Temperature | 0 °C to +60 °C (32 °F to +140 °F) |
| Dimensions | 114 mm H x 25 mm W x 38 mm D (4.5 in x 1.0 in x 1.5 in) |
| Weight | 0.1 kg (0.2 lb) |
