Product Description
__ General Information
|
Manufacturer |
Allen-Bradley |
|---|---|
|
Model/Part Number |
1747-KE/C |
|
Description |
SLC 500 Communication Interface Module |
_
__ Specifications
Power Supply Requirements
|
Voltage |
Power Consumption |
|---|---|
|
5V DC |
0.150 A (module only) / 0.150 A (module with link coupler) |
|
24V DC |
0.070 A (module only) / 0.125 A (module with link coupler) |
__Note:_If a 1747-AIC link coupler is connected with a_1747-C11 cable, the link coupler draws an additional_0.085 A at 24V DC_through the module. If connected with a_1747-C13 cable, power comes from an_SLC 500 controller_or an_external power supply.
_
Environmental Specifications
|
Specification |
Value |
|---|---|
|
Operating Temperature |
0 to 60°C (32 to 140°F) |
|
Storage Temperature |
-40 to 85°C (-40 to 185°F) |
|
Humidity |
5% to 95% non-condensing |
|
Clock/Calendar Accuracy |
±1 minute/month at 25°C (77°F)__+0, -6 minutes/month at 60°C (140°F) |
_
Electrical & Mechanical Characteristics
|
Specification |
Value |
|---|---|
|
Noise Immunity |
NEMA Standard ICS 2-230 |
|
Vibration Resistance |
0.015 in. peak-to-peak at 5-57 Hz__2.5 g at 57-2000 Hz |
|
Shock Resistance (Operating) |
30 g |
|
Port Isolation |
CONFIG Port: 500V AC__DF1 Port: 500V AC__CONFIG & DF1 Port: 500V AC |
_
