Product Description
🔹 General Information
|
Category |
Details |
|---|---|
|
Manufacturer |
Allen-Bradley |
|
Model/Part Number |
1756-HYD02 |
|
Description |
2-Channel LDT (Linear Displacement Transducer) Hydraulics Module, 36-pin |
🔹 Technical Overview
|
Attribute |
Details |
|---|---|
|
Application Type |
Kinetix Integrated Motion – Hydraulic Axis Control |
|
Channels |
2 Independent Channels |
|
Interface Type |
Analog Input Interface for Magnetostrictive LDT sensors |
|
Connector Type |
36-Pin (uses Removable Terminal Blocks, ordered separately) |
|
Supported Sensor Type |
Magnetostrictive Linear Displacement Transducers (LDT) |
|
Resolution |
High resolution position feedback |
|
Function |
Position feedback for hydraulic servo systems |
|
Mounting |
Installed in ControlLogix chassis |
|
Integration |
Compatible with Logix5000 controllers |
|
Motion Control System |
Analog Motion Module as part of Kinetix platform |
🔹 Environmental and Physical Specifications
|
Attribute |
Details |
|---|---|
|
Enclosure Type |
Open-style, for installation in enclosure |
|
Wiring Method |
Removable Terminal Block (RTB), must be selected separately |
|
Operating Temperature Range |
Typically 0…+60 °C (+32…+140 °F) |
|
Storage Temperature Range |
-40…+85 °C (-40…+185 °F) |
|
Relative Humidity |
5–95% noncondensing |
🔹 Accessories
|
Accessory |
Description |
|---|---|
|
Removable Terminal Blocks |
Required for operation (36-pin), ordered separately |
|
Cables & Connectors |
Compatible wiring for sensor integration |
