Product Description
Product Overview
The Allen-Bradley 1771-WF is a Field Wiring Arm with 18 gold-plated terminals, designed for use with PLC-5 1771 I/O modules in industrial automation systems. Manufactured by Allen-Bradley, a brand under Rockwell Automation known for its reliable control solutions, this wiring arm provides a secure and flexible connection point for field wiring, such as sensors and actuators, to isolated analog input and output modules like the 1771-IL and 1771-OFE. It features 18 screw-clamp terminals with gold plating for enhanced conductivity and corrosion resistance, supporting up to 8 I/O connection points. The 1771-WF’s hinged, swing-away design allows for easy installation and removal without disturbing connected wires, making it ideal for maintenance in legacy PLC-5 systems used in industries such as manufacturing and process control. Discontinued as part of the broader 1771 series, it remains critical for supporting existing installations.
Technical Information
| Item | Specifications |
|---|---|
| Manufacturer | Allen-Bradley (Rockwell Automation) |
| Series | PLC-5 (1771) |
| Model/Part Number | 1771-WF |
| Description | Field Wiring Arm, 18 Terminals, Gold Plated |
| Terminal Count | 18 screw-clamp terminals |
| Contact Plating | Gold |
| Wire Size | 22-14 AWG (0.324-2.08 mm²) |
| Terminal Torque | 7-9 lb-in (0.8-1 Nm) |
| I/O Points | 8 |
| Compatibility | 1771 I/O modules (e.g., 1771-IL, 1771-OFE) |
| Operating Temperature | 0 °C to +60 °C (32 °F to +140 °F) |
| Dimensions | 115 mm H x 317 mm W x 160 mm D (4.5 in x 12.4 in x 6.3 in) |
| Weight | 0.1 kg (0.2 lb) |
