Yokogawa NFLR121-S00 S1 Serial Communication Module
Yokogawa NFLR121-S00 S1 Serial Communication Module
Manufacturer: Yokogawa
Product No.: NFLR121-S00 S1
Condition:1000 in stock
Product Type: Serial Communication Module
Product Origin: Japan
Payment: T/T, Western Union
Weight: 300g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
Product Overview
The Yokogawa NFLR121-S00 S1 is a Serial Communication Module designed to exchange data with devices like PLCs via RS-422/RS-485 serial communication lines. It supports two ports with a wide range of communication speeds, making it a versatile solution for industrial systems requiring reliable serial data transfer.
Technical Specifications
The NFLR121-S00 S1 Serial Communication Module has the following specifications (specific to NFLR121 unless otherwise noted):
| Item | Specification |
|---|---|
| Model | NFLR121 |
| Interface | RS-422/RS-485 (2 ports) |
| How Connected | Multipoint |
| How Communicates | Half-duplex/Full-duplex (*1) |
| How Synchronizes | Start-stop synchronization |
| Communication Speed | 0.3, 1.2, 2.4, 4.8, 9.6, 14.4, 19.2, 28.8, 38.4, 57.6, 76.8, 115.2 kbps |
| Transmission Code | ASCII/binary |
| Character Length | 7/8 bits |
| Stop Bit | 1/2 bits |
| Parity Check | None/even/odd |
| Transmission Distance | Maximum 1200 m (total extended length) |
| Wiring Connection (*2) | Clamped with terminal block__ M4 screws (5 poles x 2) (*4) |
| Current Consumption | 500 mA |
| Weight | 0.3 kg |
Terminal Block Details
The NFLR121 RS-422/RS-485 Communication Module Terminal Block (M4 Screws) has the following pin assignments:
| Terminal Symbol | Signal Name | Function |
|---|---|---|
| TX+ | Send Data | Data transmission (common mode signal) |
| TX- | Send Data | Data transmission (reverse phase signal) |
| RX+ | Received Data | Data reception (common mode signal) |
| RX- | Received Data | Data reception (reverse phase signal) |
| SG | Signal Ground | Signal grounding |
Model and Suffix Codes
The NFLR121-S00 S1 includes the following configuration details:
| Category | Details |
|---|---|
| Model | NFLR121 RS-422/RS-485 Communication Module (2-port, 300 bps to 115.2 kbps) |
| Suffix Codes |
|
_
_
_
| Check below popular items for more information in_ | Industrial Control Hub | |||
| Brand | Description | _Price (USD)_ | Stock | Link |
| YOKOGAWA | AFV30D-S41251 S2 Control Unit | 5214-6214 | 916 | AFV30D-S41251 S2 Control Unit |
| YOKOGAWA | ADV151-P63/D5A00 Digital Input Module | 1214-2214 | 900 | ADV151-P63/D5A00 Digital Input Module |
| YOKOGAWA | AFS30D-H4121 Duplexed Field Control Unit | 643-1643 | 119 | AFS30D-H4121 Field Control Unit |
| YOKOGAWA | ANB10D-421/CU2N/NDEL Node Unit | 2357-3357 | 365 | ANB10D-421/CU2N/NDEL Node Unit |
| YOKOGAWA | ALF111-S00 S1 Fieldbus Communication Module | 1214-2214 | 122 | ALF111-S00 S1 Fieldbus Module |
| YOKOGAWA | ADV561-P01 64-Channel Digital Output Module | 643-1643 | 252 | ADV561-P01 Digital Output Module |
| YOKOGAWA | S2MMM843-SS1030 Analog/Digital I/O Module | 1214-2214 | 798 | S2MMM843-SS1030 I/O Module |
