Product Description
Product Information
| Manufacturer | Yokogawa |
|---|---|
| Model/Part Number | ANB10D-421/CU2N/NDEL |
| Description | Node Unit for Dual-Redundant ESB Bus |
General Description
The ANB10D ESB Bus Node Unit provides an interface that communicates the analog I/O signals and contact I/O signals of a field with a Field Control Unit (FCU) via an ESB bus. It also has the functionality to supply power to the I/O modules.
Power Supply
| Voltage Range | 220-240 V AC, Frequency: 50/60 Hz <br> 24 V DC |
|---|---|
| Electric Power Consumption | - 220-240 V AC: 230 VA, 120 W - 24 V DC: 5.5 A |
Model and Suffix Codes
| Description | Model ANB10D Node Unit for Dual-Redundant ESB Bus |
|---|---|
| Suffix Codes | -4 Dual-redundant power supply 1 100 - 120 V AC power supply 2 220 - 240 V AC power supply 4 24 V DC power supply |
| Explosion Protection | - 5 Basic type with no explosion protection - 6 With ISA Standard G3 option, temperature (-20 ºC to 70 ºC) option, and no explosion protection - 7 With ISA Standard G3 option and no explosion protection - E Basic type with explosion protection - F With ISA Standard G3 option, temperature (-20 ºC to 70 ºC) option, and explosion protection - G With ISA Standard G3 option and explosion protection |
| Option Codes | - /CU2N Connector Unit for ESB Bus [part No.: S9562FA (2 pieces)] <br> - /CU2T Connector Unit with Terminator for ESB Bus [part No.: S9564FA (2 pieces)] <br> - /ATDOC Explosion Protection Manual |
Weight
Approx. 10 kg (including 8 I/O modules)
