Yokogawa NFDV561-P50 Digital Output Module
Yokogawa NFDV561-P50 Digital Output Module
Manufacturer: Yokogawa
Product No.: NFDV561-P50
Condition:1000 in stock
Product Type: Digital Output Module
Product Origin: Japan
Payment: T/T, Western Union
Weight: 300g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
Product Overview
The Yokogawa NFDV561-P50 is a Digital Output Module designed to output 64-channel transistor contact signals at 24 V DC. It features isolated outputs with a current sink format and supports various fallback options, making it a reliable component for industrial control systems requiring extensive digital output capabilities.
Technical Specifications
The NFDV561-P50 Digital Output Module has the following specifications (specific to NFDV561 unless otherwise noted):
| Item | Specification |
|---|---|
| Model | NFDV561 |
| Number of Output Channels | 64 |
| Rated Applied Voltage | 24 V DC |
| Load Voltage (*1) | 24 V DC, 100 mA |
| Field Power Supply Voltage Range | 20.4 to 26.4 V |
| Output ON Voltage Maximum Value | 2 V DC |
| Leak Current Maximum Value When Output OFF | 0.1 mA |
| Output Format | Current sink |
| Maximum Load Current (*2) | 100 mA/channel, 26.4 V |
| Withstanding Voltage | Between output signal and system: 2000 V AC for 1 minute (*5) Between commons: 500 V AC for 1 minute, common minus (_) side every 16-channel |
| Functions |
Status Output: ON/OFF status output function Output Fallback (*3) (*4): - HOLD: Holds the current states when the fallback action is triggered - OFF: Resets all the output channels to off when the fallback action is triggered - NO: Performs no fallback action |
| Output Response Time | 3 ms or less (for status output) |
| Maximum Current Consumption | 780 mA (5 V DC) 120 mA (24 V DC, field power supply) |
| Weight | 0.3 kg |
| External Connection | MIL connector cable (*5) |
Model and Suffix Codes
The NFDV561-P50 includes the following configuration details:
| Category | Details |
|---|---|
| Model | NFDV561 Digital Output Module (64-channel, 24 V DC, Isolated) |
| Suffix Codes |
|
_
_
_
| Check below popular items for more information in_ | Industrial Control Hub | |||
| Brand | Description | _Price (USD)_ | Stock | Link |
| YOKOGAWA | AFV30D-S41251 S2 Control Unit | 5214-6214 | 916 | AFV30D-S41251 S2 Control Unit |
| YOKOGAWA | ADV151-P63/D5A00 Digital Input Module | 1214-2214 | 900 | ADV151-P63/D5A00 Digital Input Module |
| YOKOGAWA | AFS30D-H4121 Duplexed Field Control Unit | 643-1643 | 119 | AFS30D-H4121 Field Control Unit |
| YOKOGAWA | ANB10D-421/CU2N/NDEL Node Unit | 2357-3357 | 365 | ANB10D-421/CU2N/NDEL Node Unit |
| YOKOGAWA | ALF111-S00 S1 Fieldbus Communication Module | 1214-2214 | 122 | ALF111-S00 S1 Fieldbus Module |
| YOKOGAWA | ADV561-P01 64-Channel Digital Output Module | 643-1643 | 252 | ADV561-P01 Digital Output Module |
| YOKOGAWA | S2MMM843-SS1030 Analog/Digital I/O Module | 1214-2214 | 798 | S2MMM843-SS1030 I/O Module |
