Product Description
š¹ General Information
|
Manufacturer |
Yokogawa |
|---|---|
|
Model/Part Number |
EB401-10 S1 / EB401-50 |
|
Description |
ER Bus Interface Master Module |
Ā
Ā
š¹ Overview
TheĀ EB401Ā ER Bus Interface Master Module enables communication between:
Ā
-
ESB Bus Node UnitĀ (Local Node) or
-
Compact Field Control Unit (for FIO)
and the
-
ER Bus Node Unit (Remote Nodes)
using theĀ ER BusĀ protocol.
Ā
Ā
š¹ Standard Specifications
|
Item |
Specification |
|---|---|
|
Function |
ER bus interface |
|
Physical Layer |
IEEE 802.3 10BASE2 |
|
Connector Type |
BNC |
|
Communication Speed |
10 Mbps |
|
Max. Transmission Distance |
185 meters (with YCB141 cable) |
|
Current Consumption |
0.7 A |
|
Weight |
Approx. 0.3 kg |
Ā
Ā
š¹ Model and Suffix Codes (EB401)
|
Suffix Code |
Description |
|---|---|
|
-5 |
Standard type withĀ no explosion protection |
|
-E |
Standard typeĀ with explosion protection |
|
0 |
Always 0 (base hardware type) |
|
1 |
WithĀ ISA Standard G3Ā environmental option |
