Product Description
Product Overview
- The Yokogawa NFSB100-S50SBT01 SB Bus Repeat Module is a compact and reliable component designed for Yokogawa’s Field Control Node (FCN) within the STARDOM control system, enhancing serial communication over the SB (System Bus) network. Supporting a high-speed baud rate of 128 Mbps and a maximum transmission distance of 8 meters per line, this module enables duplex configurations and extends connectivity for up to two additional units (three including the control unit). Powered by a 5 V DC ±5% supply with a maximum current dissipation of 500 mA, it features an SB bus T-joint, weighs 0.2 kg, and occupies one slot (Slot No. 10 for single, Nos. 9 and 10 for duplexed SB bus), offering a standard design with no explosion protection.
Technical Information
| Parameter | Specifications |
|---|---|
| Manufacturer | Yokogawa |
| Model/Part Number | NFSB100-S50SBT01 |
| Description | SB Bus Repeat Module for FCN |
| Model | NFSB100 |
| Transmission Method | Serial communication |
| Baud Rate | 128 Mbps |
| Transmission Distance | Max. 8 m per line |
| Extension Units | Max. 2 units (3 units including a control unit) |
| Duplex Configuration | Possible |
| Power Supply - Supply Voltage | 5 V DC ±5% (4.75 V to 5.25 V) |
| Power Supply - Current Dissipation | Max. 500 mA |
| Weight | 0.2 kg (0.44 lb) |
| Dimensions (WxHxD) | 32.8 x 130 x 142.5 mm (1.29 x 5.12 x 5.61 in) |
| Occupying Slots | 1 |
| Slots to be Installed In | Slot No. 10 (for single SB bus) Slot Nos. 9 and 10 (for duplexed SB bus) |
Specific Configuration
- Model/Part Number: NFSB100-S50SBT01
- Configuration Details:
- Suffix Codes: -S (Standard model), 5 (With no explosion protection), 0 (Basic type)
- Option Code: /SBT01 (With an SB bus T-joint)
