Product Description
Product Overview
| Category | Details |
|---|---|
| Manufacturer | Yokogawa |
| Model/Part Number | AIP504-11 S1 |
| Description | Vnet Coupler Unit (Style S1) designed for Yokogawa CENTUM series Distributed Control Systems, enabling communication between Field Control Stations and the Vnet control network |
| Key Features | High-speed Vnet communication, supports CENTUM CS 3000 and VP systems, Style S1 hardware revision, reliable network connectivity, compact design |
Technical Specifications
| Specification | Details |
|---|---|
| Model | AIP504-11 S1 |
| Product Type | Vnet Coupler Unit |
| Series | CENTUM (CS 3000, VP) |
| Communication Protocol | Vnet |
| Power Supply | Typically 24 VDC (via system backplane) |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Weight | Approx. 0.2-0.4 kg (0.44-0.88 lbs) |
External Connection Options
| Connection Type | Details |
|---|---|
| Supported Connections | Vnet coaxial cable ports, integrates with CENTUM Field Control Station (FCS) |
Functional Features
| Feature | Details |
|---|---|
| Network Communication | Facilitates high-speed data exchange between FCS and Vnet control network |
| Compatibility | Supports CENTUM CS 3000 and CENTUM VP systems |
| Reliability | Style S1 revision ensures stable network performance in industrial environments |
| Installation | Compact unit for easy integration into FCS cabinets |
Model and Configuration
| Category | Details |
|---|---|
| Base Model | AIP504 |
| Configuration | -11: Standard type, S1: Style 1 revision |
