Product Description
🔹 Product Overview
|
Category |
Details |
|---|---|
|
Manufacturer |
Yokogawa Electric Corporation |
|
Model/Part Number |
ANB10D-425 / CU2T |
|
Description |
Dual-redundant ESB Bus Node Unit with terminator connector; interfaces analog/contact I/O signals with FCU and provides power to I/O modules |
🔹 General Specifications
|
Item |
Specification |
|---|---|
|
Model |
ANB10D |
|
Bus Type |
Dual-redundant ESB Bus |
|
Function |
Communicates analog/contact I/O signals to FCU; supplies power to I/O modules |
|
Weight |
Approx. 10 kg (including 8 I/O Modules) |
🔹 Power Supply
|
Voltage |
Frequency |
Power Consumption |
|---|---|---|
|
220–240 V AC |
50/60 Hz |
230 VA / 120 W |
|
24 V DC |
— |
5.5 A |
🔹 Model and Suffix Codes
|
Category |
Details |
|---|---|
|
Base Model |
ANB10D – Node Unit for Dual-Redundant ESB Bus |
|
-4 |
Dual-redundant power supply |
|
2 |
220–240 V AC power supply |
|
5 |
Basic type with no explosion protection |
🔹 Options
|
Option Code |
Description |
|---|---|
|
/CU2T |
Connector Unit with Terminator for ESB Bus (Part No.: S9564FA × 2) |
|
/CU2N |
Connector Unit for ESB Bus (Part No.: S9562FA × 2) |
|
/ATDOC |
Explosion Protection Manual |
