Product Description
🔍
Product Overview
|
Field |
Details |
|---|---|
|
Manufacturer |
Triconex |
|
Model/Part Number |
9662-610F |
|
Model Type |
Digital Output Termination Panel (Commoned) |
|
Description |
24 VDC, 16-point panel with commoned PWR+ and PWR– lines |
|
Usage |
Used with self-protected digital output modules |
⚙️
Technical Specifications – 9662-610F
|
Feature |
Specification |
|---|---|
|
Panel Type |
Commoned |
|
Total Points |
16 output points |
|
Power Terminals |
Shared PWR+ and PWR– for all channels |
|
Max. Total Current |
16 A (limited to 10 A when used with Model 3625 for dissipation) |
|
Fusing |
Internal protection via module (self-protected modules only) |
|
Labels |
Two sets: 1–16 and 17–32 |
⚠️ Note: Use only with self-protected modules.
🔌
Compatible Modules
|
Module Part Number |
Points/Module |
Description |
|---|---|---|
|
3624 |
16 |
24 VDC, commoned, supervised, opto-isolated, self-protected, TMR |
|
3625 |
32 |
24 VDC, commoned, supervised/non-supervised, opto-isolated, self-protected |
|
3664 |
32 |
24 VDC, commoned, opto-isolated, self-protected, dual-channel |
|
3674 |
32 |
24 VDC, commoned, opto-isolated, self-protected, dual-channel |
