Product Description
Triconex 9852 2-Channel Universal Input Module
Product Overview
- The Triconex 9852 is a 2-Channel Universal Input Module designed for the Triconex Safety Instrumented System (SIS), part of Schneider Electric’s EcoStruxure Tricon platform. It provides flexible, high-integrity input processing for safety-critical applications, supporting multiple signal types per channel. Used in industries like oil and gas, chemical, and power generation, the 9852 ensures reliable data acquisition within the Triple Modular Redundant (TMR) architecture, meeting Safety Integrity Level 3 (SIL3) requirements.
Technical Specifications
- The 9852 has the following specifications based on standard characteristics for this model:
| Specification | Details |
|---|---|
| Model/Part Number | 9852 |
| Manufacturer | Triconex (Schneider Electric) |
| Description | 2-Channel Universal Input Module |
| Series | Tricon Safety System |
| Input Channels | 2 universal inputs, user-configurable |
| Input Types | Supervised Digital Input (24 VDC, 1 ms SOE), Supervised Digital Output (24 VDC), Analog Input (0-20 mA, with/without HART), Analog Output (0-20 mA, with/without HART) |
| Safety Integrity Level | SIL3 (TÜV certified) |
| Sequence of Events (SOE) | 1 ms timestamp resolution |
| Power Consumption | Approx. 5 W |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Humidity | 5% to 95% non-condensing |
| Weight | Approx. 0.5 kg |
Additional Details
- The 9852 includes the following additional information based on its standard use and documentation:
- Function: Processes multiple input types (digital and analog) for safety applications like emergency shutdown (ESD), fire and gas detection, and process control, ensuring high-integrity data acquisition within the TMR framework.
- Mounting: Installs in Tricon chassis (e.g., 8110, 8400) slots, interfacing with the system backplane; mechanically keyed for correct placement.
- Compatibility: Compatible with Tricon v9.6 and later systems; integrates with EcoStruxure Foxboro DCS, SCADA, and HMI systems via protocols like Modbus and OPC. Supports HART pass-through for advanced device diagnostics.
- Configuration: Configurable via TriStation 1131 software; each channel can be independently set for digital or analog input/output functions, supporting up to 64 TMR I/O points in universal I/O enclosures.
- Certifications: TÜV Rheinland certified for SIL3 (IEC 61508); meets UL, CE, and Factory Mutual (FM) standards for Class I, Division 2 hazardous locations; complies with IEC 61131 environmental and EMC requirements.
