Triconex 9563-8XX Digital Input Termination Panel
Product Overview
- The Triconex 9563-8XX is a Digital Input Termination Panel designed for Triconex safety instrumented systems (SIS) by Schneider Electric. Belonging to the Triconex Other Modules series, this panel interfaces digital input modules with field devices, such as sensors and switches, ensuring reliable signal transmission in triple modular redundant (TMR) architectures. It is critical for safety applications in industries like oil and gas, chemical, and power generation, supporting fault-tolerant operation.
Technical Specifications
- The 9563-8XX has the following specifications based on standard characteristics for this model series, exemplified by the 9563-810:
| Specification | Details |
|---|---|
| Model/Part Number | 9563-8XX (e.g., 9563-810) |
| Manufacturer | Triconex (Schneider Electric) |
| Description | Digital Input Termination Panel |
| Series | Triconex Other Modules |
| Signal Type | Digital Input, 24 VDC |
| Channel Capacity | 16 points |
| Connector Type | Terminal blocks for field wiring, multi-pin connector for I/O module |
| Protection | Fused inputs with blown-fuse indicators |
| Leakage Current per Point | Maximum: 3.3 mA, Typical: 2.5 mA |
| Dimensions | 11.43 cm Width (across DIN rail), 12.7 cm Length (along DIN rail), 10.795 cm Height (out from DIN rail) |
| Operating Temperature | -20°C to 70°C (-4°F to 158°F) |
| Weight | Approx. 1.5 kg |
Additional Details
- The 9563-8XX includes the following additional information based on its standard use and documentation, particularly for the 9563-810 variant:
- Function: Connects field devices, such as digital sensors or switches, to Triconex digital input modules (e.g., 3503E, 3505E), transmitting input signals for safety monitoring in TMR systems.
- Compatibility: Compatible with Triconex Tricon v9–v10 systems; typically used with 24 VDC digital input modules and cables like 4000094-310 or 9101-010F.
- Configuration: Features commoned power terminals (PWR+ and PWR–) and fused input points for protection; includes two sets of labels (1-16 and 17-32) for use with 32-point modules requiring two panels; supports TMR fault tolerance.
- Certifications: Meets CE, UL, and IEC 61508 standards for Safety Integrity Level 3 (SIL3) applications; certified for hazardous environments.
