Product Description
Product Overview
| Category | Details |
|---|---|
| Manufacturer | Triconex (Schneider Electric) |
| Model/Part Number | 2481 |
| Description | Analog Output Baseplate Kit for Triconex Trident safety systems, designed to interface with analog output modules for controlling process variables in safety-critical environments |
| Key Features | Supports 8-channel analog output modules, triple modular redundancy (TMR), includes I/O baseplate and interconnect assembly, hot-swappable, SIL 3 certified, 4-20 mA output |
Technical Specifications
| Specification | Details |
|---|---|
| Model | 2481 |
| Product Type | Analog Output Baseplate Kit |
| Series | Trident Safety System |
| Output Channels | 8 (per module) |
| Output Type | Analog, 4-20 mA |
| Resolution | 12 bits |
| Isolation | Optically isolated outputs, channel-to-channel and channel-to-backplane |
| Power Supply | 24 VDC (via chassis backplane) |
| Operating Temperature | -40°C to 70°C (-40°F to 158°F) |
| Dimensions | Approx. 300 x 100 x 200 mm (11.8 x 3.9 x 7.9 in) |
| Weight | Approx. 1.5 kg (3.3 lbs) |
| Certifications | SIL 3 (IEC 61508), CE |
External Connection Options
| Connection Type | Details |
|---|---|
| Supported Connections | Terminal cover for field wiring, integrates with Trident chassis backplane, compatible with 3481 analog output module |
Functional Features
| Feature | Details |
|---|---|
| Analog Output Interface | Connects analog output modules to field devices for precise control |
| Redundancy | Supports TMR architecture for fault-tolerant operation |
| Hot-Swappable | Allows module replacement without system shutdown |
| Diagnostics | Built-in diagnostics for output status and baseplate health |
Model and Configuration
| Category | Details |
|---|---|
| Base Model | 2481 |
| Configuration | Standard, non-redundant baseplate, compatible with 3481 analog output module |
