Bently Nevada 3500/22-01-01-02 3500/22M TDI Module and I/O
Bently Nevada 3500/22-01-01-02 3500/22M TDI Module and I/O
Manufacturer: Bently Nevada
Product No.: 3500/22-01-01-02
Condition:1000 in stock
Product Type: 3500/22M TDI Module and I/O
Product Origin: USA
Payment: T/T, Western Union
Weight: 910g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
__ General Information
|
Manufacturer |
Bently Nevada |
|---|---|
|
Model/Part Number |
3500/22-01-01-02 |
|
Description |
3500/22M TDI Module and I/O |
_
__ Description
The_3500/22M Transient Data Interface (TDI)_serves as the_interface_between the_3500 monitoring system_and compatible software, including:
__System 1 Condition Monitoring and Diagnostic Software
__3500 System Configuration Software
The_TDI module_combines the function of a_3500/20 Rack Interface Module (RIM)_with the_data collection capability_of a_communication processor_(such as TDXnet).
_
__ Specifications
Inputs
|
Attribute |
Value |
|---|---|
|
Power Consumption |
10.5 Watts |
Data Communication
|
Port Type |
Details |
|---|---|
|
Front Panel USB |
USB-B |
|
10Base-T/100Base-TX I/O |
Ethernet (Auto-Sensing) |
|
100Base-FX I/O |
Fiber-Optic Ethernet |
_
__ Environmental Limits
|
Attribute |
Value |
|---|---|
|
Operating Temperature |
-30°C to +65°C (-22°F to +149°F) |
|
Storage Temperature |
-40°C to +85°C (-40°F to +185°F) |
|
Humidity |
95%, non-condensing |
Battery Life
|
Condition |
Battery Life @ 50°C (122°F) |
|---|---|
|
Powered TDI |
38 years |
|
Unpowered TDI |
12 years |
_
__ Physical Specifications
TDI Module
|
Attribute |
Value |
|---|---|
|
Dimensions (H x W x D) |
241.3 mm x 24.4 mm x 241.8 mm_(9.50 in x 0.96 in x 9.52 in) |
|
Weight |
0.91 kg_(2.0 lbs) |
I/O Modules
|
Attribute |
Value |
|---|---|
|
Dimensions (H x W x D) |
241.3 mm x 24.4 mm x 99.1 mm_(9.50 in x 0.96 in x 3.90 in) |
|
Weight |
0.20 kg_(0.44 lbs) |
_
__ Ordering Information
|
Part Number |
Description |
|---|---|
|
3500/22 |
TDI Module |
Customization Options
|
Code |
Transient Data Interface Type |
|---|---|
|
01 |
Standard (Use for standard monitoring applications) |
|
Code |
I/O Module Type |
|---|---|
|
01 |
10Base-T/100Base-TX Ethernet |
|
02 |
100Base-FX (Fiber Optic) Ethernet |
|
03 |
10Base-T/100Base-TX Ethernet with gold-plated OK Relay contacts |
|
04 |
100Base-FX (Fiber Optic) Ethernet with gold-plated OK Relay contacts |
|
Code |
Agency Approval |
|---|---|
|
00 |
None |
|
01 |
CSA/NRTL/C (Class 1, Division 2) |
|
02 |
Multi (CSA, ATEX, IECEx) |
_
Check below popular items for more information in_Industrial Control Hub
|
Brand |
Model |
Description |
Link |
|---|---|---|---|
|
Bently Nevada |
3500/22M 288055-01 + 146031-01 |
TDI Module with I/O Module |
|
|
Bently Nevada |
3500/22M 288055-01 |
Transient Data Interface Module |
|
|
Bently Nevada |
3500/22 146031-01 |
Tx I/O Module |
|
|
Bently Nevada |
3500/22-01-01-01 (138607-01) |
TDI Module + I/O Module |
|
|
Bently Nevada |
3500/22M 138607-01 + 146031-01 |
Transient Data Interface Module with I/O |
|
|
Bently Nevada |
3500/22-01-01-01 (138607-01 + 146031-01) |
TDI + I/O Combination Module |
|
|
Bently Nevada |
3500/22-01-01-02 |
TDI Module and I/O |
|
|
Bently Nevada |
3500/22M-01-01-00 |
TDI Module and I/O |
_
| Check below popular items for more information in_ | Industrial Control Hub | |||
| Brand | Description | _Price (USD)_ | Stock | Link |
| Bently Nevada | 3500/42 Proximitor/Seismic Monitor (01-01) | _901-1901_ | 300 | Proximitor/Seismic Monitor |
| Bently Nevada | 3500/94 VGA Display Monitor (145988-01) | _901-1901_ | 400 | VGA Display Monitor |
| Bently Nevada | 3500/25 Enhanced Keyphasor Module (01-01-01, 149369-01 + 125800-01) | _818-1818_ | 500 | Enhanced Keyphasor Module |
| Bently Nevada | 3500/25 Enhanced Keyphasor Module (149369-01) | _818-1818_ | 600 | Enhanced Keyphasor Module |
| Bently Nevada | 16710-08 Interconnect Cable | _777-1777_ | 700 | Interconnect Cable |
| Bently Nevada | 1701/25 Seismic Input Monitor for Velocity Input (01) | _748-1748_ | 200 | Seismic Input Monitor |
