Bently Nevada 3500/22-01-01-01 138607-01+146031-01 3500/22M TDI Module
Bently Nevada 3500/22-01-01-01 138607-01+146031-01 3500/22M TDI Module
Manufacturer: Bently Nevada
Product No.: 138607-01+146031-01
Condition:1000 in stock
Product Type: 3500/22M Transient Data Interface (TDI) Module
Product Origin: USA
Payment: T/T, Western Union
Weight: 910g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
__ General Information
|
Manufacturer |
Bently Nevada |
|---|---|
|
Model/Part Number |
3500/22-01-01-01 |
|
Series |
_ |
|
Description |
3500/22M Transient Data Interface (TDI) Module |
_
_
__ Description
The_3500/22M Transient Data Interface (TDI)_is a key module in the Bently Nevada 3500 Series machinery protection system. It functions as:
_
-
A_3500/20 Rack Interface Module (RIM)
-
A_communication processor_(similar to TDXnet)
-
An interface between the 3500 system and_System 1_Condition Monitoring & Diagnostic software
-
A port for_3500 System Configuration software
This TDI version supports high-speed_data acquisition_and_system communications, allowing advanced diagnostics and configuration.
_
_
__ Specifications
_
Inputs & Power
|
Parameter |
Value |
|---|---|
|
Power Consumption |
10.5 Watts |
_
Communication
|
Interface |
Type |
|---|---|
|
Front Panel |
USB-B |
|
Ethernet I/O |
10Base-T / 100Base-TX (autosensing) |
|
Fiber I/O_(optional) |
100Base-FX Fiber-Optic Ethernet |
_
_
__ Physical Specifications
_
TDI Module
|
Parameter |
Value |
|---|---|
|
Dimensions |
241.3 mm _ 24.4 mm _ 241.8 mm(9.50 in _ 0.96 in _ 9.52 in) |
|
Weight |
0.91 kg (2.0 lbs) |
_
I/O Module
|
Parameter |
Value |
|---|---|
|
Dimensions |
241.3 mm _ 24.4 mm _ 99.1 mm(9.50 in _ 0.96 in _ 3.90 in) |
|
Weight |
0.20 kg (0.44 lbs) |
_
_
__ Environmental Limits
|
Parameter |
Value |
|---|---|
|
Operating Temperature |
-30°C to +65°C (-22°F to +149°F) |
|
Storage Temperature |
-40°C to +85°C (-40°F to +185°F) |
|
Humidity |
95%, non-condensing |
_
_
__ Battery Life
|
Condition |
Battery Life |
|---|---|
|
Powered TDI |
38 years @ 50°C (122°F) |
|
Unpowered TDI |
12 years @ 50°C (122°F) |
_
_
__ Ordering Information Breakdown
|
Part Number |
Meaning |
|---|---|
|
3500/22-01-01-01 |
-_01: Standard TDI Type___-_01: 10Base-T/100Base-TX Ethernet I/O___-_01: CSA/NRTL/C (Class 1, Division 2) Agency Approval |
_
_
__ Spares
|
Part Number |
Description |
|---|---|
|
146031-01 |
10Base-T/100Base-TX I/O Module |
|
138607-01 |
3500/22M TDI Module (Standard) |
_
_
Check below popular items for more information in_Industrial Control Hub
|
Brand |
Model |
Description |
Link |
|---|---|---|---|
|
Bently Nevada |
3500/22M 288055-01 + 146031-01 |
TDI Module with I/O Module |
|
|
Bently Nevada |
3500/22M 288055-01 |
Transient Data Interface Module |
|
|
Bently Nevada |
3500/22 146031-01 |
Tx I/O Module |
|
|
Bently Nevada |
3500/22-01-01-01 (138607-01) |
TDI Module + I/O Module |
|
|
Bently Nevada |
3500/22M 138607-01 + 146031-01 |
Transient Data Interface Module with I/O |
|
|
Bently Nevada |
3500/22-01-01-01 (138607-01 + 146031-01) |
TDI + I/O Combination Module |
|
|
Bently Nevada |
3500/22-01-01-02 |
TDI Module and I/O |
|
|
Bently Nevada |
3500/22M-01-01-00 |
TDI Module and I/O |
