Bently Nevada 3500/94 145988-01 VGA Display Monitor
Bently Nevada 3500/94 145988-01 VGA Display Monitor
Manufacturer: Bently Nevada
Product No.: 3500/94 145988-01
Condition:1000 in stock
Product Type: VGA Display Monitor
Product Origin: USA
Payment: T/T, Western Union
Weight: 730g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
Product Information: Bently Nevada 3500/94 VGA Display Monitor
| Manufacturer | Bently Nevada (A Baker Hughes Business) |
|---|---|
| Series | 3500/94 |
| Model/Part Number | 3500/94 145988-01 |
| Model Type | VGA Display Monitor |
General Description
The 3500/94 VGA Display Monitor is part of Bently Nevada's 3500 Series machinery protection system. This module provides a graphical interface for displaying various system parameters, including system and alarm event lists, all module and channel data, and real-time alarm/OK status. The unit can show nine custom display options, enhancing the operator__ ability to monitor and manage machinery health effectively.
Key Specifications
| Specification | Details |
|---|---|
| Power Consumption | 4.6 watts max. |
| Inputs | RS232 port for I/O, Touch controller data. |
| Outputs | |
| OK LED | Indicates proper operation of the module. |
| TX/RX LED | Indicates communication between system modules. |
| VGA Port | Analog red, green, blue, and sync signals to the display. |
| Front Port | 24 Vdc power out, VGA signal out, touch commands in. |
Environmental Limits
| Environmental Condition | Limits |
|---|---|
| Operating Temperature | -20°C to 65°C (-22°F to 149°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity | 95%, non-condensing |
Physical Dimensions
| Specification | Details |
|---|---|
| Display Module Dimensions | 241.3 mm x 24.4 mm x 241.8 mm (9.5 in x 0.96 in x 9.52 in) |
| Weight (Display Module) | 0.73 kg (1.6 lb.) |
| I/O Module Dimensions | 241.3 mm x 24.4 mm x 99.1 mm (9.50 in x 0.96 in x 3.90 in) |
| Weight (I/O Module) | 0.34 kg (0.75 lb.) |
Ordering Information
| Option | Details |
|---|---|
| A: Display Size and Mounting | |
| 00 | None |
| 01 | 10" display, face mount (only for rack-mounted 3500 monitor) |
| 02 | 10" display, 19" rack mount |
| 03 | 10" display, panel mount (installation hardware included) |
| 04 | 10" display, independent mount |
| 05 | 15" display, 19" rack mount |
| 06 | 15" display, panel mount (installation hardware included) |
| 07 | Router box, no display |
| B: KVM Extender and Display Router Box Cables | |
| 00 | None |
| 01 | Wired CAT5 UTP KVM extender and cable 250 ft (76.2 m) |
| 02 | Wired CAT5 UTP KVM extender and cable 500 ft (152.4 m) |
| 03 | Wired CAT5 UTP KVM extender and cable 1,000 ft (304.8 m) |
| 12 | Display Router Box cable 20 ft (6 m) |
| 20 | SM FO KVM SNGL extender and cable 2,000' (609.6 m) |
| 21 | SM FO KVM SNGL extender and cable 4,000' (1219.2 m) |
| 22 | SM FO KVM SNGL extender and cable 6,000' (1828.8 m) |
| 23 | SM FO KVM SNGL extender and cable 8,000' (2438.4 m) |
| 24 | SM FO KVM SNGL extender with patch cables |
| 25 | SM FO KVM DUAL extender and cable 2,000' (609.6 m) |
| 26 | SM FO KVM DUAL extender and cable 4,000' (1219.2 m) |
| 27 | SM FO KVM DUAL extender and cable 6,000' (1828.8 m) |
| 28 | SM FO KVM DUAL extender and cable 8,000' (2438.4 m) |
| 29 | SM FO KVM DUAL extender with patch cables |
| C: Agency Approvals | |
| 00 | None |
| 01 | CSA/NRTL/C (Class I, Division 2) |
| 02 | Multi (CSA/ATEX/IECEx) (only available for the 10" display) |
_
| Check below popular items for more information in_ | Industrial Control Hub | |||
| Brand | Description | _Price (USD)_ | Stock | Link |
| Bently Nevada | 3500/15 Power Supply Module (133292-01) | _1774-2774_ | 500 | Power Supply Module |
| Bently Nevada | P1407030-00100 Proximity Probe | _0-950_ | 200 | Proximity Probe |
| Bently Nevada | 130118-0010-02 Electrical Cable Wire | _44-1044_ | 300 | Electrical Cable Wire |
| Bently Nevada | 21747-075-00 Probe Extension Cable | _499-1499_ | 200 | Probe Extension Cable |
| Bently Nevada | 3300/20 PLC Module Rack (12-01-01-00-00) | _36-1036_ | 400 | PLC Module Rack |
| Bently Nevada | 330103-00-13-10-12-00 3300 XL 8 mm Proximity Probes | _0-920_ | 500 | 3300 XL 8 mm Proximity Probes |
| Bently Nevada | 330180-12-05 3300 XL Proximitor Sensor | 724-1724 | 400 | 3300 XL Proximitor Sensor |
| Bently Nevada | P1407030-02006 Proximity Probe | _0-957_ | 700 | Proximity Probe |
