3BSE024388R1 | ABB PFXA401 PFXA 401 Control Unit
3BSE024388R1 | ABB PFXA401 PFXA 401 Control Unit
Manufacturer: ABB
Product No.: 3BSE024388R1
Condition:1000 in stock
Product Type: PFXA 401 Control Unit
Product Origin: Switzerland
Payment: T/T, Western Union
Weight: 5000g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
General Information
|
Parameter |
Value |
|---|---|
|
Manufacturer |
ABB |
|
Model/Part Number |
PFXA 401 |
|
Product ID |
3BSE024388R1 |
|
ABB Type Designation |
PFXA 401 |
|
Catalog Description |
PFXA 401 Control Unit |
|
Country of Origin |
United States, Sweden |
|
Product Type |
Control Unit |
_
Ordering Information
|
Parameter |
Value |
|---|---|
|
Customs Tariff Number |
85389091 |
|
Dangerous Goods UN Classification |
Class 9: Miscellaneous Dangerous Substances and Articles, Including Environmentally Hazardous Substances |
|
Dangerous Goods UN Number |
UN3091-PI970 |
|
Minimum Order Quantity |
1 piece |
|
Order Multiple |
1 piece |
|
Made To Order |
No |
|
Quote Only |
No |
|
Selling Unit of Measure |
Piece |
|
Stocked At (Warehouses) |
Malmö, Sweden |
_
Dimensions & Weight
|
Parameter |
Value |
|---|---|
|
Gross Volume |
8 dm³ |
|
Gross Weight |
5 kg |
|
Package Level 1 Gross Weight |
5 kg |
|
Package Level 1 Units |
1 piece |
|
Product Net Weight |
5 kg |
_
Technical Specifications
|
Parameter |
Value |
|---|---|
|
Analog Inputs |
2 |
|
Angle Compensation |
For Load Cell QGPR 102/104 (max. 2 MN) |
|
Load Cell Compatibility |
PFBL 101/141 (Max 2 _ 400 kN) |
|
Edge Sensor Compatibility |
PMSG 123 / 125 |
|
Battery |
Lithium battery, 3BSC790006R1 |
|
Fuse |
2A 250V, 3BSC770029R17 |
Connection Terminals:
|
Terminal |
Type |
Part Number |
|---|---|---|
|
X1 |
Mains Connection (4-pole) |
2664197-4 |
|
X2 |
Sync (3-pole) |
2664177-3 |
|
X3, X13, X5, X15 |
4-pole disconnectable |
2664177-4 |
|
X8, X18, X23, X30 |
2-pole disconnectable |
2664177-2 |
|
X6, X16 |
Analog output (6-pole) |
2662177-6 |
|
X24, X25, X34, X35 |
Digital signal (5-pole) |
2664163-5 |
_
Compliance & Environmental Information
|
Parameter |
Value |
|---|---|
|
UNSPSC |
39120000 |
|
WEEE Category |
Product Not in WEEE Scope |
_
