Product Description
The SM811K01 is a safety CPU module kit designed for integration within ABB’s AC 800M hardware platform. It enables high-integrity safety applications in 800xA systems, ensuring reliability and compliance with stringent safety requirements.
General Information
| Attribute | Details |
|---|---|
| Product ID | 3BSE018173R1 |
| ABB Type Designation | SM811K01 |
| Catalog Description | SM811K01 Safety CPU module kit |
| System Compatibility | AC 800M hardware and 800xA system versions 4.1–6.0. |
Key Features and Benefits
-
Collaborative Safety CPU:
- Designed to connect to the CEX bus after the BC810 CEX bus interconnection box.
-
Comprehensive Kit Includes:
- SM811 Safety Module.
- TP868 Baseplate.
- TK852V10 Synchronization Link Cable.
-
Compact and Lightweight Design:
- Optimized for easy installation and integration.
Technical Specifications
| Parameter | Details |
|---|---|
| Weight | 0.6 kg |
| Bus Connection | CEX bus (post-BC810 interconnection). |
Applications and Use Cases
The SM811K01 Safety CPU Module Kit is essential for:
- Ensuring safety and reliability in ABB’s 800xA systems.
- Integrating into AC 800M hardware platforms for safety-critical tasks.
- Supporting legacy and new system implementations within certified safety environments.
Ordering Information
| Attribute | Details |
|---|---|
| Country of Origin | Sweden (SE) |
| Customs Tariff Number | 85389091 |
Product Categories
This module is categorized under:
-
800xA Controllers
- AC 800M Hardware (versions 4.1, 5.0, 5.1).
-
Central Units
- 800xA System (6.0).
Important Notes
- Ensure the BC810 CEX bus interconnection box is properly configured before connecting the module.
- Consult ABB documentation or contact an authorized distributor for installation and operational guidelines.
