Yokogawa SAI143-H53/A4S00
Yokogawa SAI143-H53/A4S00
Manufacturer: Yokogawa
Product No.: SAI143-H53/A4S00
Condition:1000 in stock
Product Type: Analog Input Module
Product Origin: Japan
Payment: T/T, Western Union
Weight: 390g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
Product Overview
- The Yokogawa SAI143-H53/A4S00 Analog Input Module is a high-performance component designed for Yokogawa__ industrial control systems, such as CENTUM VP or ProSafe-RS, to process 4 to 20 mA signals from field devices like transmitters. Featuring 16 isolated input channels with HART communication, this module supports dual-redundant configurations for enhanced reliability. With a rated accuracy of ±16 µA, a 40 ms data update frequency, and a transmitter power supply ranging from 16.15 V to 26.4 V, it is optimized for precise analog input handling. Weighing approximately 0.34 kg with a pressure clamp terminal block, it includes ISA Standard G3 compliance for operation in temperatures from -20 to 70°C, making it suitable for robust industrial automation applications.
Technical Information
| Parameter | Specifications |
|---|---|
| Manufacturer | Yokogawa |
| Model/Part Number | SAI143-H53/A4S00 |
| Description | Analog Input Module |
| Model | SAI143 |
| Number of Input Channels | 16 channels, module isolation |
| Rated Input Range | 4 to 20 mA |
| Permissible Input Range | 0 to 25 mA |
| Input Impedance During Power-ON | 250 Ω + Current value voltage drop in the input protection circuit inside the module |
| Input Impedance During Power-OFF | 500 kΩ minimum |
| Rated Accuracy | SAI143-H: ±16 µA (Input range 0.05 to 23 mA) |
| Data Update Frequency | 40 ms |
| Temperature Drift | ±16 µA/10°C |
| Transmitter Power Supply | 16.15 V minimum (at 20 mA) 26.4 V maximum (at 0 mA) (Output current limit: 25 mA) |
| 2/4-Wire Setting | Individual channel setting, changed by setting pins |
| Withstand Voltage | 1.5 kV AC between input signal and system for 1 minute |
| Maximum Current Consumption | 5 V system: 320 mA 24 V system: 550 mA |
| Weight | Approx. 0.34 kg (0.75 lb) (for pressure clamp terminal block or MIL cable) Approx. 0.39 kg (0.86 lb) (with signal cable interface adapter) |
| External Connection | Pressure clamp terminal, MIL cable, dedicated signal cable |
| Support PRM | Available (SAI143-H) |
| Transmitter Power Supply ON/OFF Function | Available in 2-wire setting, for all 16 channels simultaneously |
Specific Configuration
- Model/Part Number: SAI143-H53/A4S00
- Configuration Details:
- Suffix Codes: -H (With HART communication), 5 (For pressure clamp terminal block or MIL cable with no explosion protection), 3 (With ISA Standard G3 and temperature -20 to 70°C)
- Option Code: /A4S00 (With pressure clamp terminal block for analog [Model: STA4S-00])
| Check below popular items for more information in_ | Industrial Control Hub | |||
| Brand | Description | _Price (USD)_ | Stock | Link |
| YOKOGAWA | ASI133-H00 Analog Input Module | 1071-2071 | 916 | ASI133-H00 Analog Input Module |
| YOKOGAWA | F9342BL LCD Assembly | 500-831 | 327 | F9342BL LCD Assembly |
| YOKOGAWA | ANR10D-413/NDEL Node Unit | 2071-3071 | 425 | ANR10D-413/NDEL Node Unit |
| YOKOGAWA | AFV30D-S41252 Duplexed Field Control Unit | 4500-5500 | 917 | AFV30D-S41252 Field Control Unit |
| YOKOGAWA | SSC50D-S2543 Duplexed Safety Control Unit | 13786-14786 | 526 | SSC50D-S2543 Safety Control Unit |
| YOKOGAWA | SDV531-L63 Digital Output Module | 643-1643 | 493 | SDV531-L63 Digital Output Module |
| YOKOGAWA | NFDR541-P00 Relay Output Module | 500-1500 | 153 | NFDR541-P00 Relay Output Module |
