Yokogawa NFAR181-S00 S2 RTD Input Module (12-channel, Isolated)
Yokogawa NFAR181-S00 S2 RTD Input Module (12-channel, Isolated)
Manufacturer: Yokogawa
Product No.: NFAR181-S00 S2
Condition:1000 in stock
Product Type: RTD Input Module (12-channel, Isolated)
Product Origin: Japan
Payment: T/T, Western Union
Weight: 200g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
__ General Information
|
Manufacturer |
Yokogawa |
|---|---|
|
Model/Part Number |
NFAR181-S00 S2 |
|
Description |
RTD Input Module (12-channel, Isolated) |
_
_
__ Description Summary
The_NFAR181-S00 S2_is a_12-channel isolated RTD input module, designed for precise temperature measurement using_Pt100_or_JPt100_sensors. It supports multiple industrial temperature standards and ensures high accuracy and noise immunity through isolation and built-in diagnostics.
_
_
__ Technical Specifications
|
Item |
Specification |
|---|---|
|
Input Type |
RTD: Pt100, JPt100 (three-wire type) |
|
Number of Channels |
12 (Isolated) |
|
Input Standards |
JIS C 1604:1997, IEC 60751:1995 (Pt100) |
|
JIS C 1604:1989 (JPt100) |
|
|
Allowable Input Voltage |
±5 V |
|
Withstanding Voltage |
1500 V AC (input to system, 1 min) |
|
Input Resistance |
_2 MΩ (Power ON/OFF) |
|
Measurement Current |
1 mA |
|
Accuracy |
±0.03% of full scale (for 0 to 400 Ω) |
|
Wiring Resistance (per wire) |
Max. 40 Ω |
|
Total Resistance (signal + wire) |
40 Ω or less |
|
Temperature Drift |
Max. ±30 ppm/°C |
|
Burn-out Detection |
Available (UP/DOWN), detection time: 60 sec |
|
Data Refresh Cycle |
1 second |
|
Maximum Current Consumption |
450 mA (5 V DC) |
|
Weight |
Approx. 0.2 kg |
|
External Connection |
Pressure clamp terminal |
_
_
__ Model and Suffix Code Breakdown
|
Model |
NFAR181__ RTD Input Module (12-channel, Isolated) |
|---|---|
|
-S |
Standard type |
|
5 |
With no explosion protection |
|
0 |
Basic type |
|
S2 |
Likely internal designation or manufacturing revision |
_
_
__ Optional Accessories
|
Option Code |
Description |
|---|---|
|
/R8S00 |
With Pressure Clamp Terminal Block for RTD (Model: NFTR8S-00) |
|
/R8S10 |
With Pressure Clamp Terminal Block for RTD + Surge Absorber (Model: NFTR8S-10) |
_
_
| Check below popular items for more information in_ | Industrial Control Hub | |||
| Brand | Description | _Price (USD)_ | Stock | Link |
| YOKOGAWA | SEC401-51 ESB Bus Coupler Module for Network Integration | 714_1714 | 740 | SEC401-51 ESB Bus Coupler Module |
| YOKOGAWA | CP401-10 S1 Processor Module for CENTUM VP Systems | 500_1500 | 510 | CP401-10 S1 Processor Module |
| YOKOGAWA | AAI143-H50 S1/ ATK4-00 S1 Analog Input Module for 4-20mA Signals | 1286_2286 | 870 | AAI143-H50 S1 Analog Input Module |
| YOKOGAWA | NFAI143-H50-S1 Analog Input Module for Current Signals | 2357_3357 | 430 | NFAI143-H50-S1 Analog Input Module |
| YOKOGAWA | EB401-10 S1 ER Bus Interface Master Module for DCS | 571_1571 | 690 | EB401-10 S1 ER Bus Interface Module |
| YOKOGAWA | AAI135-H50/13S00 Analog Input Module for Current Signals | 1786_2786 | 320 | AAI135-H50/13S00 Analog Input Module |
| YOKOGAWA | SAI143-H33 Analog Input Module for 4-20mA Signals | 1214_2214 | 760 | SAI143-H33 Analog Input Module |
