Yokogawa NFAI135-S50/CCC01 Analog Input Module
Yokogawa NFAI135-S50/CCC01 Analog Input Module
Manufacturer: Yokogawa
Product No.: NFAI135-S50/CCC01
Condition:1000 in stock
Product Type: Analog Input Module
Product Origin: Japan
Payment: T/T, Western Union
Weight: 300g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
__ General Information
|
Manufacturer |
Yokogawa |
|---|---|
|
Model/Part Number |
NFAI135-S50/CCC01 |
|
Description |
Analog Input Module (4_20 mA, 8-Channel, Isolated Channels) |
_
_
__ Description
The_Yokogawa NFAI135-S50/CCC01_is an_8-channel, isolated analog input module_designed for receiving_4 to 20 mA DC current signals. It features_channel-to-channel and signal-to-system isolation, making it suitable for high-integrity applications such as safety or mission-critical systems. The module supports_HART communication, overcurrent protection, and transmitter power supply, with stable performance across a wide temperature range.
_
_
__ Technical Specifications
|
Item |
Specification |
|---|---|
|
Model |
NFAI135 |
|
Type |
Analog Input Module |
|
Number of Channels |
8 (isolated per channel) |
|
Input Signal |
4 to 20 mA |
|
Allowable Input Current |
25 mA |
|
Overcurrent Protection |
Provided |
|
Withstanding Voltage |
500 V AC for 1 min (channel-to-channel & input-to-system) |
|
Input Resistance (Power ON) |
250 Ω |
|
Input Resistance (Power OFF) |
_500 kΩ |
|
Accuracy |
±0.1% of full scale |
|
Data Refresh Cycle |
10 ms |
|
Input Step Response Time |
100 ms |
|
Transmitter Power Supply |
20.2 to 29.3 V DC |
|
Temperature Drift |
Max. ±0.01%/°C |
|
Max Current Consumption |
360 mA @ 5 V DC, 450 mA @ 24 V DC |
|
Weight |
Approx. 0.3 kg |
|
External Connections |
Pressure clamp terminal, MIL connector cable |
|
HART Communication |
Available (via_-H_suffix) |
_
_
__ Model and Suffix Code Breakdown
|
Model |
Description |
|---|---|
|
NFAI135 |
Analog Input Module (8-channel, 4_20 mA, Isolated) |
|
Suffix Code |
Meaning |
|---|---|
|
-S |
Standard type |
|
5 |
With no explosion protection |
|
0 |
Basic type |
|
/CCC01 |
With connector cover for MIL cable [Model: NFCCC01] |
__NFAI135-S50/CCC01_=
_
-
Standard_module
-
No explosion protection
-
Basic type
-
MIL cable cover included
_
_
__ Available Option Codes
|
Option Code |
Description |
|---|---|
|
/13S00 |
With pressure clamp terminal block [Model: NFTI3S-00] |
|
/13S10 |
With surge-absorber terminal block [Model: NFTI3S-10] |
|
/CCC01 |
With connector cover for MIL cable [Model: NFCCC01] |
_
_
| Check below popular items for more information in_ | Industrial Control Hub | |||
| Brand | Description | _Price (USD)_ | Stock | Link |
| YOKOGAWA | ALE111-S00 Ethernet Communication Module for DCS | 714_1714 | 870 | ALE111-S00 Ethernet Module |
| YOKOGAWA | AAI543-H61/K4A00 Analog Output Module for 4-20mA Signals | 3071_4071 | 430 | AAI543-H61/K4A00 Analog Output Module |
| YOKOGAWA | AAI143-S50/A4S10 Analog Input Module with HART Communication | 786_1786 | 690 | AAI143-S50/A4S10 Analog Input Module |
| YOKOGAWA | ADV551-P00 S2 Digital Output Module for 32 Channels | 500_1000 | 320 | ADV551-P00 S2 Digital Output Module |
| YOKOGAWA | SDV531-S33 S2 Digital Output Module for Safety Applications | 1786_2786 | 760 | SDV531-S33 S2 Digital Output Module |
| YOKOGAWA | YS1700 S2 Programmable Indicating Controller for Process Control | 857_1857 | 590 | YS1700 S2 Controller |
| YOKOGAWA | AFV10D-S41151 Duplexed Field Control Unit for Redundant Systems | 4500_5500 | 410 | AFV10D-S41151 Field Control Unit |
