Product Description
Product Information
| Manufacturer | Yokogawa |
|---|---|
| Model/Part Number | AIP831-101/EIM |
| Description | Operation Keyboard for Eight-loop Simultaneous Operation |
General Description
The AIP831-101/EIM is an Operation Keyboard for Eight-loop Simultaneous Operation. It includes:
- Mode selection switch
- Operation confirmation key Type A
- Always 1
- With English Instruction Manual
Hardware Specifications
| Specification | Details |
|---|---|
| Type | Flat keyboard (Sound Function: USB Speaker) |
| PC Interface | USB A type x2 |
| USB Standard | USB 2.0 (Full-speed, Bus-powered) for operation keyboard USB 1.1 (Full-speed, Bus-powered) for sound function |
| Input Voltage | 5V ± 5% (Supplied from USB Port of PC) |
| Maximum Consumption Current | 1A |
| Weight | 2.0 kg (without VESA bracket) 2.5 kg (with VESA bracket) |
| Chassis Color | Black (Munsell No. N1.5) |
| Compliance | IEC 61010-1 Installation Category Class I (A device not directly connected with the main power supply) |
Operating Environment
| Specification | Value |
|---|---|
| Ambient Temperature (Normal operation) | 5°C to 40°C |
| Ambient Temperature (Storage/Transportation) | -20°C to 60°C |
| Ambient Humidity | 20% to 80% RH (Non-condensing) |
| Touch Sensor | A touch only by the bare hand is sensed |
Model and Suffix Codes
| Description | Model AIP831 Operation Keyboard for Eight-loop Simultaneous Operation |
|---|---|
| Suffix Codes | -0 Without Mode selection switch -1 With Mode selection switch |
| Operation Confirmation Key | 0 Operation confirmation key Type A 1 Operation confirmation key Type B |
| Always 1 | 1 Always 1 |
| Option Codes | /VESA With VESA Bracket /EIM With English Instruction Manual /JIM With Japanese Instruction Manual |
