Yokogawa ADV551-P63/D5A00 32-Channel Digital Output Module
Yokogawa ADV551-P63/D5A00 32-Channel Digital Output Module
Manufacturer: Yokogawa
Product No.: ADV551-P63/D5A00
Condition:1000 in stock
Product Type: 32-Channel Digital Output Module
Product Origin: Japan
Payment: T/T, Western Union
Weight: 200g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
__ General Information
|
Manufacturer |
Yokogawa |
|---|---|
|
Model/Part Number |
ADV551-P63/D5A00 |
|
Description |
32-Channel Digital Output Module, 24 VDC, Isolated, with pulse and time-proportion functions, status display, and KS Cable Interface Adapter |
_
_
__ Specifications
|
Item |
Specification |
|---|---|
|
Number of Output Channels |
32 |
|
Rated Applied Voltage |
24 V DC |
|
External Power Supply Rating |
24 V DC, 50 mA |
|
External Power Supply Voltage Range |
20.4 to 26.4 V DC |
|
Output Format |
Current sink |
|
Output ON Voltage (Max) |
2 V DC |
|
Leak Current (Output OFF) |
Max. 0.1 mA |
|
Maximum Load Current |
100 mA per channel (at max. 26.4 V) |
|
Withstanding Voltage |
Output to system: 2 kV AC for 1 minBetween commons: 500 V AC for 1 min, grouped every 16 channels |
|
Output Response Time |
_ 3 ms (status output), _ 10 ms (mixed output modes) |
|
Pulse Width Output |
One-shot pulse output from 8 ms to 7200 s |
|
Pulse Width Resolution |
8 ms (ON/OFF delay of max. 1 ms added) |
|
Time-Proportioning Output |
Supported (ON/OFF control) |
|
Status Output Function |
Supported |
|
Maximum Current Consumption |
700 mA (5 V DC), 60 mA (external 24 V DC) |
|
Weight |
Approx. 0.20 kg |
|
External Connection |
Pressure clamp terminal, KS cable (AKB331), MIL connector |
_
_
__ Suffix Code Breakdown (ADV551-P63)
|
Code |
Meaning |
|---|---|
|
-P |
With pulse width and time-proportioning output functions |
|
6 |
With status display; no explosion protection |
|
3 |
With ISA Standard G3 and wide temperature support (-20 to 70°C) |
_
_
__ Option Code Breakdown (/D5A00)
|
Option Code |
Description |
|---|---|
|
/D5A00 |
With KS Cable Interface Adapter for 32-channel Digital Output (Model: ATD5A-00) |
_
_
