Yokogawa ADV151-E63/D5A00 2-channel Digital Input Module
Yokogawa ADV151-E63/D5A00 2-channel Digital Input Module
Manufacturer: Yokogawa
Product No.: ADV151-E63/D5A00
Condition:1000 in stock
Product Type: 2-channel Digital Input Module
Product Origin: Japan
Payment: T/T, Western Union
Weight: 300g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
__ General Information
|
Manufacturer |
Yokogawa |
|---|---|
|
Model/Part Number |
ADV151-E63/D5A00 |
|
Description |
32-channel Digital Input Module (24 V DC, SOE capture, with status display, explosion protection) |
_
_
__ Product Overview
The_ADV151-E63/D5A00_is a_32-channel isolated digital input module_designed for capturing 24 V DC ON/OFF signals. It is suitable for both_sink and source-type_inputs and supports_SOE (Sequence of Events) capture, enabling high-precision timestamping of input changes. The module can be configured in_dual-redundant systems, making it ideal for mission-critical industrial applications such as power generation and process automation. It includes_status display, is rated for_explosion protection, and supports harsh environments per_ISA G3_standards.
_
_
__ Technical Specifications
|
Item |
Specification |
|---|---|
|
Model |
ADV151 |
|
Input Channels |
32 channels |
|
Input Signal Type |
24 V DC (sink/source compatible) |
|
Input ON Voltage |
18 to 26.4 V DC |
|
Input OFF Voltage |
5.0 V DC or less |
|
Input Current (typical) |
4.1 mA ±20% per channel |
|
Max Allowable Input Voltage |
30.0 V DC |
|
Withstanding Voltage |
2 kV AC (input to system), 500 V AC between commons (every 16 channels) |
|
Status Input |
Supported (ON/OFF detection) |
|
Pushbutton Input |
Supported (edge detection up to 25 Hz) |
|
SOE Input Functionality |
Supported (SOE data capture) |
|
Input Response Time |
8 ms or less |
|
Min ON Detection Time |
20 ms (pushbutton input) |
|
Power Consumption |
500 mA (5 V DC) |
|
Weight |
Approx. 0.30 kg |
|
External Connections |
Pressure clamp terminal, MIL connector, KS cable via adapter |
_
_
__ Suffix & Option Code Breakdown
_
Suffix Codes in ADV151-E63
|
Code |
Meaning |
|---|---|
|
E |
SOE capture function enabled |
|
6 |
With status display |
|
3 |
ISA Standard G3 option and extended temp range (-20 to 70 °C) |
_
Option Code in /D5A00
|
Code |
Description |
|---|---|
|
/D5A00 |
KS Cable Interface Adapter for 32-channel Digital Input (ATD5A-00) |
_
_
| Check below popular items for more information in_ | Industrial Control Hub | |||
| Brand | Description | _Price (USD)_ | Stock | Link |
| YOKOGAWA | AAI143-H00 S2 Analog Input Module for CENTUM VP | 429_1429 | 460 | AAI143-H00 S2 Analog Input Module |
| YOKOGAWA | AAI143-S50/ATA4S-00 Analog Input Module for 4-20mA Signals | 714_1714 | 620 | AAI143-S50/ATA4S-00 Analog Input Module |
| YOKOGAWA | CP703 Processor Module for Control Systems | 929_1929 | 390 | CP703 Processor Module |
| YOKOGAWA | NFDV551-P60/D5S00 Digital Output Module for 24V DC Signals | 2071_3071 | 740 | NFDV551-P60/D5S00 Digital Output Module |
| YOKOGAWA | AIP831-011/EIM Operation Keyboard for Eight-Loop Simultaneous Operation | 2071_3071 | 510 | AIP831-011/EIM Operation Keyboard |
| YOKOGAWA | SCP451-51 S1 Processor Module for ProSafe-RS Safety Systems | 1071_2071 | 870 | SCP451-51 S1 Processor Module |
| YOKOGAWA | AAI143-H00/K4A00 Analog Input Module for 4-20mA Signals | 500_1500 | 430 | AAI143-H00/K4A00 Analog Input Module |
