Yokogawa ACG10S-F8123 Communication Gateway Unit

Product Overview

The Yokogawa ACG10S-F8123 is a Communication Gateway Unit designed to facilitate communication in industrial systems. This model, now discontinued, supports various communication modes and configurations to integrate with Yokogawa’s CENTUM VP3 system. It is available in two physical forms: a 19" rack-mountable type and a desktop type, catering to different installation needs.

Physical Characteristics

• Weight:
  • 19" Rack Mountable Type: Approx. 7.5 kg
  • Desktop Type: Approx. 6.5 kg

Model and Suffix Codes

• Model: ACG10S Communication Gateway Unit
• Suffix Codes:
  • E: Text Mode (Ethernet)
  • -F: Frame Mode, Wide Area Communication (Ethernet)
  • Communication Configurations:
    • 2:Dual-Redundant V net (10BASE-5)
    • 7:Single V net (10BASE-2)
    • 8:Dual-Redundant V net (10BASE-2)
  • Mounting Options:
    • 1:General-Purpose 19" Rack Mountable Type
    • 2:Desktop Type (*1)
  • Power Supply Options:
    • 1:100-120 V AC Power Supply
    • 2:220-240 V AC Power Supply
  • Software:
    • 3: Basic software license of Communication Gateway Unit Functions for CENTUM VP3 (LGW12 £0)
