Yokogawa AAI543-S50/ATK4A-00 Analog Output Module
Yokogawa AAI543-S50/ATK4A-00 Analog Output Module
Manufacturer: Yokogawa
Product No.: AAI543-S50/ATK4A-00
Condition:1000 in stock
Product Type: Analog Output Module
Product Origin: Japan
Payment: T/T, Western Union
Weight: 400g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
__ General Information
|
Manufacturer |
Yokogawa |
|---|---|
|
Model/Part Number |
AAI543-S50/ATK4A-00 |
|
Description |
Analog Output Module (4_20 mA, 16-Channel, Isolated, Redundant Capable) |
_
_
__ Description
The_AAI543-S50/ATK4A-00_is a 16-channel isolated analog output module delivering 4_20 mA signals. Designed for high reliability, it supports_standard switch-over response_in_dual-redundant configurations. This variant includes a_KS Cable Interface Adapter_for connection to the_AEA4D Terminal Board_using the_ATK4A-00_adapter.
_
_
__ Technical Specifications
|
Specification |
Details |
|---|---|
|
Model Base |
AAI543 |
|
Output Channels |
16, isolated |
|
Redundancy Type |
Standard switch-over response in redundant configuration |
|
Output Signal |
4 to 20 mA |
|
Withstanding Voltage |
1500 V AC between output and system (for 1 minute) |
|
Allowable Load Resistance |
0 to 750 _ |
|
Circuit-Open Detection |
Less than 0.65 mA |
|
Accuracy |
±48 µA |
|
Data Update Period |
10 ms |
|
Temperature Drift |
±16 µA per 10 _C |
|
Max Current Consumption |
230 mA (5 V DC), 540 mA (24 V DC) |
|
Weight |
0.4 kg |
|
External Communication |
Pressure clamp terminal, MIL connector, KS1 dedicated cable |
|
HART Communication |
Not available in this variant |
_
_
__ Model & Option Code Breakdown
|
Code |
Meaning |
|---|---|
|
-S |
Standard type (no HART protocol) |
|
5 |
Standard switch-over response in redundant configuration |
|
0 |
Basic type |
|
/ATK4A-00 |
With KS Cable Interface Adapter (for AEA4D Terminal Board) [Model: ATK4A-00] |
