Yokogawa AAR145-S50 S1 RTD/POT Input Module

Yokogawa AAR145-S50 S1 RTD/POT Input Module

  • Manufacturer: Yokogawa

  • Product No.: AAR145-S50-S1

  • Condition:1000 in stock

  • Product Type: RTD/POT Input Module

  • Product Origin: USA

  • Payment: T/T, Western Union

  • Weight: 1000000g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • 24/7 Support
  • 30-Day Returns
  • Fast Shipping

Product Overview

The Yokogawa AAR145-S50 S1 is an RTD/POT Input Module designed for precise signal acquisition in industrial control systems. Part of the TC/RTD Input Modules series, this 16-channel module accepts signals from resistance temperature detectors (RTD) and potentiometers (POT), with isolation between the field and system as well as between each channel. Suitable for dual-redundant configurations, it offers robust performance for temperature and position monitoring applications.

Technical Information

Item Specifications
Manufacturer Yokogawa
Model/Part Number AAR145-S50 S1
Description RTD/POT Input Module
Number of Input Channels 16, isolated channels
Input Signal RTD: JIS C1604:1997 (*3), IEC751:1995 Pt100 (3-wire type)
POT: Total resistance 100 _ to 10 k_, Span resistance 50% or larger of total resistance
Switching Input Signals RTD/POT can be selected individually for CH1 to CH16
Allowable Input Voltage ±5 V
Withstanding Voltage Between input and system: 500 V AC (for single card: 1500 V AC), 1 minute
Between input channels: 200 V AC, 1 minute
Input Resistance Power ON: 1 M_ or larger
Power OFF: 1 M_ or larger
Accuracy RTD: ±150 m_
POT: ±0.2 %/FS
Allowable Total Resistance of Signal Source Plus Wiring 150 _ or less (wiring resistance per wire) (*4)
Measurement Current RTD: 1 mA
Data Update Period 1 s
Burn-out All channels can be set together
Setting: Not available/Available (UP/DOWN)
Detection time: 60 s
Temperature Drift RTD: ±0.3 _/10 °C
POT: ±0.4 %/10 °C
Maximum Current Consumption 350 mA (5 V DC)
Weight 0.3 kg
External Connection Dedicated cable (KS8/AKB335)

Model and Suffix Codes

  • Model: AAR145 RTD/POT Input Module (16-channel, Isolated channels)
  • Suffix Codes:
    • -S: Standard type
    • 5: With no explosion protection
    • E: With explosion protection
    • 0: Basic type
    • 3: With ISA Standard G3 option and temperature (-20 to 70 °C) option

Specific Configuration

  • Model/Part Number: AAR145-S50 S1
  • Configuration Details:
    • -S: Standard type
    • 5: With no explosion protection
    • 0: Basic type
    • S1: Likely a variant or typo; interpreted as a possible error for "0" (Basic type), with "S" potentially redundant or an additional designation not listed in suffix codes
