Yokogawa AAI143-H00 S1 Analog Input Module
Yokogawa AAI143-H00 S1 Analog Input Module
Manufacturer: Yokogawa
Product No.: AAI143-H00-S1
Condition:1000 in stock
Product Type: Analog Input Module
Product Origin: Japan
Payment: T/T, Western Union
Weight: 300g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
__ General Information
|
Manufacturer |
Yokogawa |
|---|---|
|
Model/Part Number |
AAI143-H00 S1 |
|
Description |
Analog Input Module (4 to 20 mA, 16-channel, Isolated) with HART communication |
_
_
__ Description
The_AAI143-H00 S1_is a 16-channel_isolated analog input module_designed for high-reliability industrial automation systems. It supports_4 to 20 mA_analog signals and includes_digital communication (HART protocol)_for advanced diagnostics and configuration over the same signal lines.
The___00__suffix indicates:
_
-
H: HART digital communication enabled
-
0: Basic type (no G3/environmental or extended temperature options)
-
0: No explosion protection
The___1__tag typically refers to a_hardware series or version identifier.
_
_
__ Technical Specifications
|
Item |
Specification |
|---|---|
|
Model |
AAI143 |
|
Input Channels |
16, isolated |
|
Input Signal |
4 to 20 mA |
|
Allowable Input Current |
24 mA |
|
Withstanding Voltage |
1500 V AC (1 minute, input to system) |
|
Input Resistance (Power ON) |
270 _ (at 20 mA) to 350 _ (at 4 mA) |
|
Input Resistance (Power OFF) |
_500 k_ |
|
Accuracy |
±16 µA |
|
Data Update Period |
10 ms |
|
Transmitter Power Supply |
_19.0 V @ 20 mA; _25.5 V @ 0 mA (limit: 25 mA) |
|
Transmitter Type Setting |
Per channel, via setting pin (2-wire / 4-wire) |
|
Temp Drift |
±16 µA per 10 °C |
|
Max Current Consumption |
230 mA @ 5 V DC; 540 mA @ 24 V DC |
|
Weight |
0.3 kg |
|
External Communication |
Pressure clamp terminal, MIL connector, KS1 cable |
|
HART Communication |
Enabled_(digital communication supported over analog lines) |
_
_
__ Model Configuration
|
Suffix Code |
Meaning |
|---|---|
|
H |
With HART protocol support |
|
0 |
Basic type (standard coating & temp range) |
|
0 |
No explosion protection |
|
S1 |
Hardware revision or series tag |
_
_
_
| Check below popular items for more information in_ | Industrial Control Hub | |||
| Brand | Description | _Price (USD)_ | Stock | Link |
| YOKOGAWA | AAI143-H00/A4S00 Analog Input Module for 4-20mA Signals | 500_1500 | 740 | AAI143-H00/A4S00 Analog Input Module |
| YOKOGAWA | SAI143-H53/A4D00 Analog Input Module with High Precision | 1786_2786 | 510 | SAI143-H53/A4D00 Analog Input Module |
| YOKOGAWA | ANB10D-410/NDEL Node Unit for Dual Redundant ESB Bus | 2643_3643 | 870 | ANB10D-410/NDEL Node Unit |
| YOKOGAWA | NFCP501-W05/S01 CPU Module for FCN Autonomous Controller | 4500_5500 | 430 | NFCP501-W05/S01 CPU Module |
| YOKOGAWA | DP97-B Display Processor Card for Control Systems | 1329_2329 | 690 | DP97-B Display Processor Card |
| YOKOGAWA | CP451-51 S2 Processor Module for CENTUM VP | 5214_6214 | 320 | CP451-51 S2 Processor Module |
| YOKOGAWA | YNT511D-P42/KT Bus Repeater Module for Network Extension | 1643_2643 | 760 | YNT511D-P42/KT Bus Repeater |
