Yokogawa AAI143-H00/A4S00 Analog Input Module
Yokogawa AAI143-H00/A4S00 Analog Input Module
Manufacturer: Yokogawa
Product No.: AAI143-H00/A4S00
Condition:1000 in stock
Product Type: Analog Input Module
Product Origin: Japan
Payment: T/T, Western Union
Weight: 300g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
__ General Information
|
Manufacturer |
Yokogawa |
|---|---|
|
Model/Part Number |
AAI143-H00/A4S00 |
|
Description |
Analog Input Module (4_20 mA, 16-channel, Isolated) with HART & Pressure Clamp Terminal Block |
_
_
__ Description
The_AAI143-H00/A4S00_is a 16-channel isolated analog input module used in distributed control systems. It supports_4_20 mA analog signals,_HART communication, and includes the_/A4S00 option__ a_Pressure Clamp Terminal Block (ATA4S-00)_for easier field wiring.
The HART-enabled module supports digital communication over the same signal line, allowing device diagnostics, configuration, and calibration without disrupting analog signal transmission.
_
_
__ Technical Specifications
|
Item |
Specification |
|---|---|
|
Model |
AAI143 |
|
Input Channels |
16, isolated |
|
Input Signal |
4 to 20 mA |
|
Allowable Input Current |
24 mA |
|
Withstanding Voltage |
1500 V AC (1 minute, input to system) |
|
Input Resistance (Power ON) |
270 _ (at 20 mA) to 350 _ (at 4 mA) |
|
Input Resistance (Power OFF) |
_500 k_ |
|
Accuracy |
±16 µA |
|
Data Update Period |
10 ms |
|
Transmitter Power Supply |
_19.0 V @ 20 mA; _25.5 V @ 0 mA (limit: 25 mA) |
|
Transmitter Type Setting |
Per channel, via setting pin (2-wire / 4-wire) |
|
Temp Drift |
±16 µA per 10 °C |
|
Max Current Consumption |
230 mA @ 5 V DC; 540 mA @ 24 V DC |
|
Weight |
0.3 kg |
|
External Communication |
Pressure clamp terminal, MIL connector, KS1 cable |
|
HART Communication |
Available_(digital protocol supported) |
_
_
__ Model Configuration
|
Code |
Meaning |
|---|---|
|
H |
HART protocol supported |
|
00 |
Basic type, no explosion protection or environmental option |
|
/A4S00 |
Includes_Pressure Clamp Terminal Block_(ATA4S-00) |
_
_
__ Option Summary
|
Option Code |
Description |
|---|---|
|
/A4S00 |
Pressure Clamp Terminal Block (ATA4S-00) _ for simple wiring |
|
Other Options |
Surge protection, dual terminals, MIL cable covers, etc. |
_
_
_
| Check below popular items for more information in_ | Industrial Control Hub | |||
| Brand | Description | _Price (USD)_ | Stock | Link |
| YOKOGAWA | AAI143-H00/A4S00 Analog Input Module for 4-20mA Signals | 500_1500 | 740 | AAI143-H00/A4S00 Analog Input Module |
| YOKOGAWA | SAI143-H53/A4D00 Analog Input Module with High Precision | 1786_2786 | 510 | SAI143-H53/A4D00 Analog Input Module |
| YOKOGAWA | ANB10D-410/NDEL Node Unit for Dual Redundant ESB Bus | 2643_3643 | 870 | ANB10D-410/NDEL Node Unit |
| YOKOGAWA | NFCP501-W05/S01 CPU Module for FCN Autonomous Controller | 4500_5500 | 430 | NFCP501-W05/S01 CPU Module |
| YOKOGAWA | DP97-B Display Processor Card for Control Systems | 1329_2329 | 690 | DP97-B Display Processor Card |
| YOKOGAWA | CP451-51 S2 Processor Module for CENTUM VP | 5214_6214 | 320 | CP451-51 S2 Processor Module |
| YOKOGAWA | YNT511D-P42/KT Bus Repeater Module for Network Extension | 1643_2643 | 760 | YNT511D-P42/KT Bus Repeater |
