Triconex 9101-010F Fanned-Out Cable
Product Overview
- The Triconex 9101-010F is a Fanned-Out Cable designed for Triconex safety instrumented systems (SIS) by Schneider Electric. Belonging to the Triconex Other Modules series, this cable connects digital I/O modules to field devices or termination panels, providing a low-cost solution for signal transmission in triple modular redundant (TMR) architectures. It is used in safety-critical applications across industries such as oil and gas, chemical, and power generation.
Technical Specifications
- The 9101-010F has the following specifications based on standard characteristics for this model:
| Specification | Details |
|---|---|
| Model/Part Number | 9101-010F |
| Manufacturer | Triconex (Schneider Electric) |
| Description | Fanned-Out Cable |
| Series | Triconex Other Modules |
| Cable Type | Digital I/O Signal Transmission |
| Length | 10 feet (3 meters) |
| Connector Type | Multi-pin connector to individual wire terminals |
| Signal Compatibility | Digital signals (not certified for analog signals) |
| Operating Temperature | -20°C to 70°C (-4°F to 158°F) |
| Weight | Approx. 0.5 kg |
Additional Details
- The 9101-010F includes the following additional information based on its standard use and documentation:
- Function: Connects Triconex digital I/O modules (e.g., 7400210-010, 7400213-100) to field devices or termination panels, fanning out a multi-pin connector into individual wire terminals for easy field wiring.
- Compatibility: Compatible with Triconex Tricon and Tricon CX systems; designed for digital input/output modules but not certified for analog signals.
- Configuration: Offers a cost-effective alternative to standard termination panels; supports TMR architectures for fault-tolerant signal transmission; available in custom lengths in 10-foot increments up to 90 feet by modifying the part number (e.g., 9101-050 for 50 feet).
- Certifications: Meets CE, UL, and industrial standards for safety and performance in hazardous environments.
