Triconex 2201 Communication Module Modbus Protocol
Triconex 2201 Communication Module Modbus Protocol
Manufacturer: Triconex
Product No.: 2201
Condition:1000 in stock
Product Type: Communication Module
Product Origin: 8520369147852
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
Triconex 2201 Communication Module - Modbus Protocol Interface for Safety Systems
The Triconex 2201 Communication Module serves as a critical networking interface for Trident safety instrumented systems, enabling seamless data exchange between safety controllers and supervisory SCADA platforms through industry-standard Modbus RTU and Modbus TCP protocols.
Core Technical Specifications
- Protocol Support: Modbus RTU (RS-485), Modbus TCP/IP (Ethernet)
- Baud Rate Range: 1200 to 115200 bps (RS-485)
- Network Speed: 10/100 Mbps auto-negotiation (Ethernet)
- Data Capacity: Up to 2048 registers per transaction
- Response Time: <50 ms typical for register reads
- Isolation: 2500 VAC optical isolation on serial ports
- Operating Temperature: -40°C to +70°C (-40°F to +158°F)
- Diagnostic LEDs: Power, TX/RX activity, fault indication
Industrial Application Environments
Deployed extensively in oil refineries, chemical processing plants, offshore platforms, and power generation facilities where real-time safety data must be transmitted to distributed control systems (DCS) and human-machine interfaces (HMIs). The 2201 module bridges the gap between safety-critical Triconex controllers and enterprise-level monitoring infrastructure, maintaining data integrity through cyclic redundancy checks and timeout protection mechanisms.
Integration Advantages
Hot-swappable installation allows module replacement during system operation without disrupting safety functions. The 2201 automatically synchronizes with the Tricon backplane upon insertion, inheriting network configuration from the controller's memory. Supports both master and slave operating modes, enabling flexible network topologies including star, ring, and daisy-chain configurations. Compatible with third-party Modbus devices through standard function code implementation (FC01-FC06, FC15-FC16).
Technical Support Questions
Q: Can the 2201 handle simultaneous Modbus RTU and TCP connections?
A: Yes, the module supports concurrent operation on both serial and Ethernet interfaces, allowing redundant communication paths for enhanced reliability.
Q: What's the maximum cable distance for RS-485 connections?
A: Up to 1200 meters (4000 feet) at lower baud rates (9600 bps or below) using twisted-pair cable with proper termination resistors at both ends.
Q: Does the 2201 require special configuration software?
A: Configuration is performed through TriStation 1131 programming software, where you define register mappings, protocol parameters, and network addresses within the safety logic project.
Warranty and Support Coverage
Each Triconex 2201 module includes a comprehensive 12-month warranty protecting against manufacturing defects and component failures. Our technical support team provides configuration assistance, troubleshooting guidance, and protocol optimization recommendations throughout the product lifecycle. All units undergo factory testing per IEC 61508 standards before shipment.
Compatible System Components
| Product Model | Function | Product Link |
|---|---|---|
| Triconex AP3101 | Advanced communication processor with multi-protocol support | View AP3101 Module |
| Triconex 4352B | High-speed communication module for distributed architectures | View 4352B Module |
| Triconex 3805E | Analog output module for process control integration | View 3805E Module |
