Product Description
Product Overview
The HIMA F8627X is an Ethernet Communication Module designed for use in HIMA safety-related control systems, such as the H41q and H51q series. This module enhances communication capabilities by supporting SafeEthernet for secure data exchange between programmable electronic systems (PES) and ELOP II TCP for programming over Ethernet (from OS version 7.x). It is an upgraded version of the F8627, typically deployed in industrial safety applications like oil & gas, chemical processing, and power generation, where reliable and fast communication is critical for achieving safety integrity levels up to SIL 3.
Technical Specifications
The F8627X has the following specifications based on standard characteristics for this model:
| Item | Specification |
|---|---|
| Model/Part Number | F8627X |
| Manufacturer | HIMA |
| Description | Ethernet Communication Module |
| Communication Interfaces | Ethernet (100Base-TX, IEEE 802.3), high-speed serial, serial (RS-485) |
| Transmission Rate | Up to 100 Mbps (Ethernet) |
| Power Supply | 5 V DC (via system backplane) |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Weight | Approximately 0.45 kg (1 lb) |
Additional Details
The F8627X includes the following additional information based on its standard use and documentation:
| Category | Details |
|---|---|
| Function | Enables SafeEthernet communication and ELOP II TCP programming |
| Mounting | Plugs into HIMA system rack (e.g., H41q/H51q central module subrack) |
| Compatibility | HIMA H41q/H51q systems, up to 64 PES units, integrates with F8650X/F8652X CPUs |
| Features | Supports SafeEthernet, ELOP II TCP (OS V7.x+), OPC DA, mono or redundant configurations |
| Certifications | Suitable for SIL 3 applications per IEC 61508 |
| Part Type | New, surplus, or refurbished; successor to F8627 |
