Product Description
Product Overview
The HIMA F3DIO8/801 is a Safety-Related Remote I/O Module from the HIMatrix series, designed for industrial automation tasks requiring high safety standards. Manufactured by HIMA, this compact module integrates 8 digital inputs, 8 digital outputs, and 2 pulsed outputs in a metal enclosure. It connects to HIMax or HIMatrix controllers via SafeEthernet, extending I/O capabilities in safety-critical applications such as oil & gas, chemical processing, and power generation. The module is certified for use up to SIL 3 per IEC 61508.
Technical Specifications
The F3DIO8/801 has the following specifications based on standard characteristics for this model:
| Item | Specification |
|---|---|
| Model/Part Number | F3DIO8/801 |
| Manufacturer | HIMA |
| Description | Safety-Related Remote I/O Module |
| Series | HIMatrix |
| Digital Inputs | 8 (24 V DC) |
| Digital Outputs | 8 (24 V DC, 0.5 A per channel at 60°C; 1 A for outputs 4 and 8 up to 50°C) |
| Pulsed Outputs | 2 |
| Power Supply | 24 V DC |
| Operating Temperature | -25°C to 60°C (-13°F to 140°F) |
| Weight | 1.0 kg (2.2 lbs) |
Additional Details
The F3DIO8/801 includes the following additional information based on its standard use and documentation:
| Category | Details |
|---|---|
| Function | Processes safety-related digital inputs and outputs remotely |
| Mounting | DIN rail mountable |
| Compatibility | HIMax and HIMatrix controllers via SafeEthernet |
| Features | LED indicators per output, 2-pole connection option for outputs 4 and 8, SIL 3 certified |
| Certifications | SIL 3 per IEC 61508, Cat. 4 and PL e per EN ISO 13849-1 |
