Product Description
Product Details
|
Manufacturer |
HIMA |
|---|---|
|
Model/Part Number |
F3AI08/401 |
|
Description |
Safety-Related Controller |
Technical Specifications
General
|
Parameter |
Value |
|---|---|
|
Response Time |
≥ 20 ms |
|
Ethernet Interfaces |
2 x RJ-45, 10BASE-T/100BASE-Tx with integrated switch |
|
Operating Voltage |
24 VDC, -15…+20 %, rPP ≤ 15 % (from a power supply unit with safe insulation per IEC 61131-2) |
|
Current Input (Max Load) |
0.8 A |
|
Idle Current |
Approx. 0.4 A at 24 V |
|
External Fuse |
10 A time-lag (T) |
|
Back-up Battery |
None |
|
Operating Temperature |
0…+60 °C |
|
Storage Temperature |
-40…+85 °C |
|
Type of Protection |
IP20 |
|
Max. Dimensions (Without Plug) |
Width: 207 mm (with housing screws) Height: 114 mm (with fixing bolt) Depth: 97 mm (with earthing rail) |
|
Weight |
Approx. 1 kg |
