Product Description
Product Details
|
Manufacturer |
HIMA |
|---|---|
|
Model/Part Number |
62100 984162100 |
|
Description |
2-Fold Analog Limit Monitor |
Technical Specifications
Analog Section
|
Parameter |
Value |
|---|---|
|
Input Voltage |
0…5.5 V |
|
Input Current |
0…22 mA (250 Ω Shunt) |
|
Measuring Range (NE 43 Standard) |
I > 3.6 mA, I < 21 mA |
|
Input Resistance |
≥ 100 kΩ |
|
Basis Error |
≤ 0.25% of upper value (+25°C) |
|
Operating Error |
≤ 0.4% of upper value (-25°C to +70°C) |
|
Resolution |
12 Bit (upper value including overflow) |
|
Filter Constant |
10 ms |
Digital Section
|
Parameter |
Value |
|---|---|
|
Switching Time |
< 250 ms |
|
Output Current Limit |
0.11 A ± 10% |
|
Internal Voltage Drop |
2.5 V at max. load |
|
Minimum Load |
12 kΩ (no lamp load) |
|
Maximum Inductivity |
1 H |
|
Safety Time |
250 ms |
|
Operating Data |
24 V DC / 170 mA, plus load |
|
Space Requirement |
3U high, 4SU |
Fault Indication Relay
|
Parameter |
Value |
|---|---|
|
Contact Material |
Ag alloy, gold-plated |
|
Switching Voltage |
≤ 30 V DC / AC, ≥ 10 mV |
|
Switching Current |
≤ 1 A, ≥ 10 mA |
|
Switching Capacity (DC) |
≤ 30 W, non-inductive |
|
Switching Capacity (AC) |
≤ 60 VA, cos φ > 0.7 |
|
Bounce Time |
< 2 ms |
|
Mechanical Life |
> 10⁷ switching cycles |
|
Electrical Life |
> 10⁵ switching cycles (resistive load, ≤ 0.1 switching cycles/s) |
