Product Description
Product Overview
The ABB REF615C_E HCFDACADABC2BAN11E is a Feeder Protection and Control Relay from the Relion® 615 series, designed for the protection, control, measurement, and supervision of utility and industrial power distribution systems. Manufactured by ABB, this Intelligent Electronic Device (IED) is specifically engineered for overhead lines and cable feeders in radial, looped, or meshed networks, including those with distributed power generation. It offers advanced protection functions, such as overcurrent, earth-fault, and voltage protection, along with control and monitoring capabilities. The detailed part number suffix (HCFDACADABC2BAN11E) indicates a specific configuration tailored to customer requirements, including hardware and software options.
Technical Specifications
The REF615C_E HCFDACADABC2BAN11E has the following specifications based on standard characteristics for the REF615 series:
| Item | Specification |
|---|---|
| Model/Part Number | REF615C_E HCFDACADABC2BAN11E |
| Manufacturer | ABB |
| Description | Feeder Protection and Control Relay |
| Series | Relion® 615 |
| Input Voltage (Power Supply) | 48-250 V DC or 100-240 V AC, 50/60 Hz |
| Current Inputs | 4 (3 phase + 1 residual, 1/5 A configurable) |
| Voltage Inputs | 3 (phase voltages, configurable) |
| Digital Inputs | 10 (configurable, based on “C” hardware) |
| Digital Outputs | 8 (configurable, based on “C” hardware) |
| Operating Temperature | -25°C to +55°C (-13°F to +131°F) |
| Weight | Approximately 4.1 kg (9 lbs, complete unit) |
Additional Details
The REF615C_E HCFDACADABC2BAN11E includes the following additional information based on its standard use and configuration breakdown:
| Category | Details |
|---|---|
| Function | Feeder protection, control, measurement, and supervision |
| Mounting | Panel-mounted (flush or semi-flush) |
| Connectivity | IEC 61850, Modbus, DNP3, optional Ethernet |
| Features | Overcurrent protection, earth-fault protection, auto-reclosing, HMI with graphical display |
| Certifications | IEC 60255, CE, UL (depending on configuration) |
