Emerson EMU10 DC Monitoring Module with 7-Inch Touchscreen

Emerson EMU10 DC Monitoring Module - Advanced Power System Supervision with 7-Inch Touchscreen Display

The Emerson EMU10 DC Screen Monitoring Module delivers comprehensive real-time monitoring and control for DC power systems in telecommunications, utilities, and industrial applications. Featuring a high-resolution 7-inch TFT touchscreen display, ARM9 industrial processor, and multi-protocol communication capabilities, this advanced monitoring solution provides operators with instant visibility into charging module performance, system health, and power quality metrics critical for mission-critical infrastructure.

Core Technical Specifications

• Model Number: EMU10 (Alternate: EMU10LC)
• Display: 7-inch TFT true color LCD touchscreen, high resolution
• Processor: ARM9 industrial-level processor for reliable performance
• Voltage Monitoring Range: DC 12V to 50V
• Response Time: <2 milliseconds for rapid anomaly detection
• Communication: 10/100Mbps Ethernet, RS485, reserved IEC61850 interface
• Time Synchronization: iRIG-B hard pair time signal input support
• Power Consumption: 1W (ultra-low power design)
• Operating Temperature: -40°C to +85°C (-40°F to 185°F)
• Protection Rating: IP65 (dustproof and splash-proof)
• Dimensions: 125mm (L) x 52mm (W) x 22mm (H)
• Weight: Approximately 0.5 kg

Global Safety & Environmental Certifications

Certified for deployment in harsh industrial and telecommunications environments:

• CE Marking: European conformity for electrical safety and EMC compliance
• RoHS Compliant: Restriction of Hazardous Substances directive compliance
• FCC Certified: Federal Communications Commission electromagnetic interference standards
• IP65 Protection: Complete dust protection and water jet resistance for outdoor installations

Telecommunications & Industrial Applications

Telecom Central Office Monitoring: Supervise DC power distribution systems serving switching equipment, transmission gear, and network infrastructure in telecommunications central offices. The 7-inch touchscreen provides operators with real-time visibility into rectifier module status, battery voltage, load current, and system alarms without requiring separate monitoring computers. Multi-language support (Chinese/English switching) accommodates international deployments and multilingual operations teams.

Utility Substation DC Systems: Monitor DC control power for protection relays, SCADA systems, circuit breaker controls, and substation automation equipment. The <2 millisecond response time enables rapid detection of voltage transients, ground faults, and power supply failures that could compromise protective relay operation. IEC61850 interface support facilitates integration with modern digital substations and smart grid infrastructure.

Data Center Power Management: Provide centralized monitoring for DC power distribution serving servers, storage arrays, and network equipment in data centers and colocation facilities. Ethernet connectivity enables integration with building management systems (BMS) and data center infrastructure management (DCIM) platforms for comprehensive facility monitoring. Historical data logging supports capacity planning and energy efficiency optimization.

Industrial Battery Charging Systems: Supervise battery charging operations in UPS systems, emergency lighting, and backup power applications across manufacturing facilities, hospitals, and critical infrastructure. Real-time voltage and current monitoring ensures batteries remain within optimal charging parameters, extending battery life and preventing premature failures. Alarm notifications alert maintenance personnel to charging anomalies requiring immediate attention.

Railway Signaling Power Systems: Monitor DC power distribution for railway signaling equipment, interlocking systems, and train control infrastructure. The rugged IP65 enclosure withstands vibration, temperature extremes, and environmental contaminants common in railway environments. M12 connector ensures secure, vibration-resistant connections that maintain signal integrity despite mechanical stress.

Advanced Monitoring & Control Features

Comprehensive capabilities for power system supervision:

High-Precision Voltage Measurement: Monitor DC voltages from 12V to 50V with high accuracy across the full operating range. The <2 millisecond response time captures transient voltage events that slower monitoring systems miss, enabling rapid identification of power quality issues, ground faults, and rectifier failures before they impact critical loads.

Intuitive Touchscreen Interface: The 7-inch TFT true color LCD provides crisp, high-resolution graphics visible in bright sunlight and low-light conditions. Touch and key input modes accommodate different operator preferences and enable operation with gloved hands in cold environments. Customizable display layouts allow operators to prioritize the most critical parameters for their specific application.

ARM9 Industrial Processor: The ARM9 processor architecture delivers reliable performance in harsh environments with extended temperature ranges (-40°C to +85°C). Wind River software platform ensures deterministic real-time operation with customizable functions tailored to specific monitoring requirements. Online software updates enable feature enhancements without hardware replacement.

Multi-Protocol Communication: Ethernet (10/100Mbps) enables TCP/IP connectivity for remote monitoring via web browsers or SCADA systems. RS485 serial communication supports Modbus RTU protocol for integration with legacy monitoring equipment. Reserved IEC61850 interface provides future-proof compatibility with intelligent electronic devices (IEDs) in digital substations.

Time Synchronization: iRIG-B time signal input ensures precise time stamping of events, alarms, and data logs. Synchronized time stamps enable correlation of power system events with other facility systems, supporting root cause analysis during outages or equipment failures. GPS-disciplined time sources maintain accuracy within microseconds for regulatory compliance and forensic analysis.

Environmental Specifications

System Integration Capabilities

Flexible connectivity for diverse monitoring architectures:

• Ethernet Connectivity: 10/100Mbps auto-negotiating Ethernet port supports TCP/IP, SNMP, and web server protocols for remote access
• RS485 Serial: Modbus RTU protocol enables integration with PLCs, RTUs, and legacy SCADA systems
• IEC61850 Ready: Reserved interface for future integration with digital substation automation systems
• Web-Based Monitoring: Built-in web server allows remote monitoring via standard web browsers without proprietary software
• Data Logging: Internal memory stores historical voltage, current, and alarm data for trend analysis and reporting

Why Choose Industrial Control Hub?

Your specialized source for genuine Emerson power monitoring solutions:

• ✓ 100% authentic OEM products with full manufacturer traceability and warranty
• ✓ Expert power systems technical support from certified engineers
• ✓ Extensive inventory of current production and legacy monitoring modules
• ✓ Expedited global shipping to US, UK, EU, and Asia-Pacific markets
• ✓ Competitive pricing with volume discounts for project quantities
• ✓ Complete documentation, configuration guides, and commissioning assistance

Complementary Power System Components

Installation & Configuration

• Mounting: Panel mount or DIN rail installation options (mounting hardware included)
• Power Input: DC 12V to 50V operating range accommodates various system voltages
• Communication Wiring: Ethernet RJ45 connector, RS485 terminal block, M12 connector for field connections
• Time Sync Input: iRIG-B time signal input via dedicated terminal
• Initial Setup: Touchscreen configuration wizard guides operators through initial system setup

Ordering Information & System Planning

• EMU10 (EMU10LC): DC Screen Monitoring Module with 7-Inch Touchscreen (this product)
• Voltage Range: DC 12V to 50V monitoring capability
• Communication: Ethernet, RS485, IEC61850 (reserved) interfaces
• Multi-Module Systems: Multiple EMU10 units can be networked for distributed monitoring
• Software Customization: Contact factory for custom display layouts and alarm configurations

Technical Documentation & Support

Complete installation manuals, communication protocol specifications, web interface user guides, and commissioning procedures available upon request. Our application engineering team provides system design consultation, network integration assistance, custom software configuration, and troubleshooting support for complex multi-site DC power monitoring deployments.

Maintenance & Service Life

• MTBF: >50,000 hours at 25°C ambient temperature
• Preventive Maintenance: Clean touchscreen monthly, verify communication links quarterly, update firmware annually
• Touchscreen Lifespan: >1 million touch operations before degradation
• Expected Service Life: 10-15 years in typical telecom/industrial environments
• Firmware Updates: Online updates via Ethernet without hardware replacement
