Bently Nevada 3500/05-01-02-00-00-00 System Rack

Bently Nevada 3500/05-01-02-00-00-00 System Rack

  • Manufacturer: Bently Nevada

  • Product No.: 3500/05-01-02-00-00-00

  • Condition:1000 in stock

  • Product Type: System Rack

  • Product Origin: USA

  • Payment: T/T, Western Union

  • Weight: 5000g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • 24/7 Support
  • 30-Day Returns
  • Fast Shipping

Product Details

Manufacturer Bently Nevada
Model/Part Number 350005-01-02-00-00-00
Description 3500 System Rack

Description

The 3500 System Rack is used to mount all 3500 monitor modules and power supplies. It allows modules to be positioned near one another for effective communication and power distribution.

  • Rack Sizes Available:
    • Full-size rack: 19-inch EIA rack with 14 available module slots.
    • Mini-rack: 12-inch rack with seven available module slots.

Ordering Information

Product Code Details
3500/05-AA-BB-CC-DD-EE
A: Rack Size 01: 19-inch Rack (14 module slots)
02: 12-inch Mini-Rack (7 module slots)
B: Mounting Options 01: Panel Mount, Full-Size Rack
02: Rack Mount, Full-Size Rack
03: Bulkhead Mount, Full-Size Rack (not available for Mini-Rack)
04: Panel Mount, Mini-Rack
05: Rack Mount, Mini-Rack
C: Agency Approval Option 00: None
01: CSA/NRTL/C (Class 1, Division 2)
02: ATEX/IECEx/CSA (Class 1, Zone 2)
D: Reserved 00: None
E: European Compliance Option 01: CE

Specifications

Rack Dimensions (Full-Size)

Dimension Measurement
Without Internal Barriers 265.94 mm x 482.60 mm x 349.25 mm
With Internal Barriers 265.94 mm x 482.60 mm x 422.91 mm
Depth (inches) 13.750 in., 16.650 in. (with barriers)
